Help CenterDC ATX Power Pico Psu IDDDIP380A Aokpower Factory Direct
Product Spotlights
Stable and reliable
US$ 10
≥100 Units
Key Specifications
Get Latest Price
Feature:
Other, DC Input
Power:
<300W
ATX Standard:
ATX 12V 2.3
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
25 days
Related Products
-
DC ATX Power Pico Psu Input19V 24V 120W Aokpower Factory DirectUS$ 10MOQ: 50 Units -
DC DC ATX Power Pico Psu ATX Board Aokpower Factory Direct SaleUS$ 7.5MOQ: 100 Units
-
CRPS 2U 2400W Server Power Cage AOKPOWER Factory Direct SaleUS$ 40MOQ: 100 Units
-
CRPS to ATX Power Module AOKPOWER Factory Direct SaleUS$ 10MOQ: 100 Units
-
Crps Power Cage Plug in 2400W Aokpower Factory DirectUS$ 40MOQ: 100 Units
Feature
Other, DC Input
Power
<300W
ATX Standard
ATX 12V 2.3
Hard Disk Interface
≤2
80PLUS Certification
80 PLUS Gold
Modular
Modular
Use
Desktop
Specification
300W
Product Category：DC ATX Power
◆Dimensions（MM）：In-line（24P）
◆Input voltage：+12V/DC（11.4V-12.6V）
◆Output Power：380W
◆Overall efficiency：≥96%
◆Operating temperature：0℃～40℃
◆Storage temperature：-20℃～80℃
Output characteristics:
The output voltage |
Minimum(V) |
Max(V) |
Light load(A) |
Overload(A) |
Ripple(mV) |
Wire color |
Short circuit protection |
+12V |
11.40 |
12.60 |
0 |
17.5 |
120MAX |
Yellow |
Down |
+5V |
4.75 |
5.25 |
0 |
10 |
70MAX |
Red |
Down |
-12V |
-10.80 |
-13.20 |
0 |
0.1 |
240MAX |
Blue |
Non |
+3.3V |
3.14 |
3.47 |
0 |
10 |
50MAX |
Orange |
Down |
+5VSB |
4.75 |
5.25 |
0 |
1 |
70MAX |
Purple |
Down |
Applications: MINI computers, all-in-one computers, POS machines, digital set-top boxes, ITX chassis, network servers, advertising machines, bank terminals, low-power systems, industrial control systems, etc.
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2010
Factory Size
5,000-10,000 square meters
Annual Export Value
US$5 Million - US$10 Million
