SOI Nanosecond High Speed Switch 2x2

SOI Nanosecond High Speed Switch 2x2 thumbnail-1
SOI Nanosecond High Speed Switch 2x2 photo-1
US$ 1800 ≥1 Piece
Key Specifications
Get Latest Price
Certification:
ISO
Condition:
New
Contact Supplier Request Quote Chat Now
Sichuan Ziguan Optoelectronics Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Certification ISO
Condition New

1x2 2x2 Silicon-based Nanosecond Optical Switch (SM)



Features

Excellent optical properties

Super-fast response time

High reliability

All solid structure

No moving parts,compact construction

Applications

Optical switching

High- speed network protection

Precision instrument

Medicine,aerospace,sensing



Parameters

NS High-speed optical switch 1x2 2x2

Min.

Typ.

Max.

Unit

Wavelength

1310/1550

nm

Loss

1.6

2.0

dB

Crosstalk

18

25

35

dB

PDL

0.15

0.3

dB

Return loss

45

50

60

dB

Response time

10ns/ 300ns

ns

Fiber type

                  SMF-28e


Input optical power

300

mW

Driving voltage

＜1

V

Operating temperature

-5

70

oC

Storage temperature

-40

85

oC

Size

131.75*7*8mm




Ordering information

ZG

Switching time

Wavelength

Channel

Fiber type

Fiber cover

Pigtail length

Connector

Package

10=10ns

30=300ns

13=1310nm

15=1550nm

1=1x2

2=2x2

SM

PM



0=Bare fiber         09=0.9mm

2=2mm





1=1m

2=2m

NE=None

FA=FC/APC

FP=FC/PC

XX=others

M=Module

B=Benchtop


Product Tags: nanosecond switch , high speed switch , 2x2 optical switch
