Product Introduction
01 Product Application
These cables are used for power supply in low-voltage installation systems.
They are suitable for installation indoors and outdoors, in cable ducts, underground, in power plants and switch stations,
local energy distribution, industrial plants and other places where there is no risk of mechanical damage.
02 Product Features
Black type sheath: Can be used for UV resistance
Flame retardancy
03 Technical Certification
Complies with RoHS standard
Complies with 2014/35/EU - Directive ("Low Voltage Directive") CE
Product Structure
Conductor material: Bare copper wire
Conductor class: Complies with IEC60228 cl.5 standard
Insulation: Cross-linked polyethylene (XLPE) or polyvinyl chloride (PVC)
Core identification: Black cores with white numbers, with or without GNYE
Stranding: Layered stranding
Armor: Steel wire braided armor
Outer sheath: PVC
Sheath color: Black, RAL9005 or grey RAL7001
Rated voltage: 0.6/1kV
Test voltage: 4kV
Conductor resistance: Complies with IEC60228 cl.5 standard
Capacitance: Core/core about 120nF/km; Core/shield about 160nF/km
Minimum bending radius: 7.5xd
Minimum bending radius: 15xd
Temperature rating for fixed use: -15°C/+90°C
Temperature rating for mobile use: -5°C/+90°C
Flame retardant rating: IEC60332-1-2
Standards: HD 603-3G IEC60502
Product identification: Aein bei ke SHANGHAI AEIN WIRE & CABLE CO,LTD Model Specification Voltage CE Meter mark
