N2XH CPR B2ca-s1a, d0, a1 grade power cable


· Flame retardancy meets CPR B2ca-s1a, d0, a1 grade


· Non-propagation performance meets IEC 60332-3-24


· Halogen-free meets IEC 60754-1 (total amount of halogen acid gas)


· Corrosiveness of combustion gas meets IEC 60754-2 (acidity)


· Low smoke density, meets IEC 61034-2



Used for buildings or industrial buildings with dense personnel or valuable items; for the connection of key equipment such as elevators, fire protection systems, lighting systems, etc.; in public facilities such as hospitals, schools, shopping malls, etc., all internal wiring.


Conductor material: Bare copper or tinned copper


Conductor grade: Meets IEC 60228 cl.5 standard


Insulation: XLPE


Core wire identification: Black core wire with white numbers (customizable colors)


Stranding: Layered stranding


Outer sheath: LSZH


Sheath color: Black RAL9005 (customizable colors)


Rated voltage: 0.6/1kV


Test voltage: 4kV


Conductor resistance: Meets IEC 60228 cl.5 standard


Bending radius: For mobile installation: 7.5 x d; for fixed installation: 15 x d


Temperature range: -40°C/+90°C


Flame retardant grade: CPR B2ca-s1a, d0, a1 grade


Product identification: Aein beike SHANGHAI AEIN WIRE& CABLE CO.LTD Model Specification Voltage CE Meter mark


· Meets RoHS standard


· Complies with CPR certification standards


· Complies with 2014/35/EU - Directive ("Low Voltage Directive") CE
