Tanzaina Gold Mining Equipment 6S4450 Gold Shaking Table Gravity Separation In Stock
Product Overview
The 6S shaking table (also called 6S gold shaker table or fiberglass gravity concentrating table) is one of the most reliable and cost-effective fine mineral separation machines in the mining industry. Driven by an eccentric linkage mechanism, it uses the combined action of deck vibration, transverse water flow and riffle traps to separate gold, tin, tungsten, chrome, coltan and other heavy minerals from gangue based on specific gravity difference.
With a wear-resistant fiberglass deck reinforced with corundum, adjustable stroke/frequency/slope, and 90–95% recovery on 0.037–2 mm particles, the 6S model is widely used as the final cleaning stage after trommel, jig or centrifugal concentrator in both alluvial gold wash plants and hard-rock gold processing lines.
How 6S Gold Shaking Table Works
Ore slurry is fed from the upper corner of the inclined deck while clean water flows across the riffles. Under asymmetric reciprocating motion (slow forward, fast return), high-density particles like gold settle into the riffles and move toward the concentrate discharge edge, while light tailings are washed down the lower side. The result is a clear fan-shaped distribution of concentrate – middling – tailings that operators can visually monitor and adjust in real time.
Key Specifications (6-S 7.6 Standard Deck)
-
Deck size: 4500 × 1850 mm (transmission end) / 1550 mm (concentrate end)
Beneficiation area: 7.6 m²
Feeding size: 0–2 mm (coarse deck 0.5–2 mm / fine sand deck 0.074–0.5 mm / slime deck 0.037–0.074 mm)
Capacity: 1–1.8 t/h (single deck)
Stroke: 16–22 mm (adjustable)
Frequency: 220–320 r/min
Motor power: 1.1 kW
Water consumption: 0.7–1 t/h
Recovery rate: 90–95% on fine gold
Deck options: coarse sand / fine sand / slime; rectangular, sawtooth or triangular riffles
Voltage: 220V/380V/440V customizable
Smaller models (6-S 4.08 / 1.95 / 0.5) are available for lab use, pilot plants and containerized mobile gold plants.
Core Selling Points
High fine-gold recovery – captures flakes and micron gold that pans, sluices or spirals lose.
Interchangeable decks – one frame serves coarse, fine and slime ores by swapping the fiberglass deck.
Chemical-free gravity separation – no mercury, no cyanide, environmentally compliant for EU/US/AU import.
Heavy-duty fiberglass deck – corrosion-proof, non-deforming under wet slurry, far longer life than wooden or alloy decks.
Fully adjustable – stroke, frequency, longitudinal & transverse slope tuned to your ore grade and feed size.
Low OPEX – 1.1 kW motor, 0.7–1 t/h water, one worker can run multiple tables.
Typical Application Flow (Alluvial Gold)
Trommel scrubber → Centrifugal concentrator / jig (roughing) → 6S gold shaking table (cleaning) → Final gold concentrate ≥ 90% purity
Middlings can be recycled to the table feed to push total plant recovery up by 8–15%.
Minerals Separated
Gold (placer & lode), silver, tin, tungsten, tantalite-columbite, ilmenite, zircon, chrome, manganese, lead-zinc, copper oxide, rare earth tailings.
Why Buy From Us
-
Factory-direct price, MOQ 1 set, 7–15 days lead time for standard 6-S 7.6
ISO9001 + CE export certificates, video inspection before shipment
Spare decks, riffle kits, motors in stock
Free ore-testing recommendation (send 5 kg sample, we return flow sheet + deck type)
Engineers available for overseas installation or online commissioning
-
Custom logo, voltage, deck color, left/right hand configuration
