Help CenterSERVOPRO MultiExact 4100 Gas Flow Analyzer
Product Spotlights
Related Products
-
WinCC RT V7.5 SP1 Asia 512 Power Tags by Proxy BeitouUS$ 2788 - 2800MOQ: 1 Box -
Supply S7-1500 Series PLC 6ES7677-2DB42-0GK0 Brand New InUS$ 2900 - 2960MOQ: 1 Unit
-
Original BSH0703P11A2A Servo Motor Lexium BSH SeriesUS$ 512 - 595MOQ: 1 Unit
-
Our Company Supplies P F UC4000-30GM-IUR2-V15 Ultrasonic Sensor.NegotiableMOQ: 1 Unit
-
ET 200SP New Original 6ES7677-2AA41-0FK0 Open CPUNegotiableMOQ: 1 Unit
Optional sensor technology:
O ₂ purity/control: paramagnetic (non loss type, with temperature and pressure compensation)
O ₂ Trace (ppm level): Zirconia
CO ₂/CO/N ₂ O/CH ₄ (trace): Gas filtration related infrared (GFC/GFx)
CO ₂/CH ₄ (% level): Single beam dual wavelength infrared (SBDW/SBSW)
Background gas identification (such as Ar/N ₂/He): Thermal conductivity (TCD)
Humidity Expansion: Can integrate third-party alumina humidity sensors (such as Easidew TX 97166)
Function and Interface
Operating interface: color touch screen, icon driven; Support USB data recording, configuration backup/cloning (USB flash drive), and remote upgrade.
Signal input/output:
Analog output: Each channel comes standard with 1 × 4-20 mA (optional 2 channels+0-10 V)
Analog input: up to 4 × 4-20 mA
Digital input: up to 8 channels (2 channels per sensor)
Relay/Alarm: Standard configuration includes 4 relays+2 alarms, expandable to 32 relays+32 alarms
Communication protocols: RS232/RS485 (Modbus), PROFIBUS; Optional Ethernet (Modbus TCP/IP)
Installation methods: desktop (432 × 141.2 × 543.6 mm), rack mounted (19 inches, 482.6 × 132.5 × 543.6 mm); The host weighs approximately 14 kg
Hefei Maideli Electrical Technology Co., Ltd. is an engineering service company specializing in the sales, technical services, and training of industrial automation products and CNC systems.
Sales agent CP network card, frequency converter, touch screen, low-voltage electrical appliances, sensors, CNC servo spare parts. Various industrial electronic components, etc
Our company has a complete range of models and numerous brands in stock all year round, with reasonable prices. We serve domestic and foreign customers all year round, providing technical support, selection, and accessories for customers! To solve problems for customers and truly achieve time-saving, worry free, and labor-saving, the company adheres to the principle that closing deals is just the beginning of service! Our business philosophy has won the cooperation and support of many domestic enterprises! Hefei Maideli looks forward to your consultation and cooperation!
There are many brands and models, and not all of them can be displayed. Please contact us for consultation
