Help CenterElectric Power Line Suspension Porcelain Insulator 10kv 35kv Factory Direct With Logistics Included
Related Products
-
Power Fittings Matching Suspension Insulators and Suspension Porcelain Insulators 10kv 35kv Stock WholesaleUS$ 1.38MOQ: 100 Pieces -
110kv Suspension Insulator, Suspension Porcelain Insulator, High-voltage Power Line Insulator, Customization SupportedUS$ 1.38MOQ: 100 Pieces
-
35kv Suspension Insulator, Suspension Porcelain Insulator for Power Lines, Steel Cap Disc Porcelain InsulatorUS$ 1.38MOQ: 100 Pieces
-
110kv Line Suspension Insulator Porcelain Tensile-resistant High-strength Porcelain InsulatorUS$ 1.38MOQ: 100 Pieces
-
Suspension Porcelain Insulator for 10kv Transmission Line, Anti-pollution and Anti-flashover Ceramic InsulatorUS$ 1.38MOQ: 100 Pieces
In the operating environment of power transmission lines, insulators assume the dual responsibilities of electrical insulation and mechanical support, directly affecting the long-term stability of the transmission system. Lines are exposed to industrial pollution, salt spray, and temperature variations over long periods, causing the porcelain surface to accumulate contaminants and form leakage currents, which can lead to pollution flashovers in severe cases. Meanwhile, working conditions such as conductor loads and ice accretion impose stringent challenges on the mechanical strength of insulators. Improper selection or unreliable quality can cause accidents such as conductor dropout and flashovers, increasing operation and maintenance costs. Therefore, power engineering customers require suspension insulators with excellent pollution resistance, stable electromechanical strength, and reliable production traceability.
Hejian Haokang Electric Co., Ltd. specializes in the manufacturing of electrical porcelain products, with a main product lineup covering suspension insulators, pin insulators, porcelain cross-arms, post insulators, and various electrical porcelain bushings, forming a complete product system covering both line porcelain and station porcelain. Based on an in-depth understanding of industry pain points, Hejian Haokang Electric Co., Ltd. continuously optimizes raw material formulations, forming processes, and firing control—using selected porcelain raw materials, processed through ball milling, vacuum pugging, forming, automatic glazing, and electric kiln firing, resulting in dense porcelain bodies and smooth glazed surfaces, improving surface hydrophobicity and self-cleaning performance. At the same time, strict in-process inspection controls mechanical strength, ensuring long-term reliable operation of products on 10kV/35kV lines. The factory-direct delivery model shortens the supply chain, reduces overall procurement costs at the source, and supports customization according to engineering requirements.
Suspension insulators (commonly known as suspension porcelain insulators) are typically composed of a porcelain body, a metal cap, a steel pin, and connecting fittings. The porcelain body provides high insulation resistance and low dielectric loss; the metal cap and steel pin bear mechanical tensile loads. In use, multiple insulator units are connected in series according to the system voltage level, with the number of units determined by the system voltage, tower dimensions, and environmental pollution levels. For 10kV lines, the insulator string is relatively short, usually consisting of one to several units; for 35kV lines, the voltage is higher and the required number of units increases accordingly. The shed structure of each insulator unit effectively extends the surface creepage distance, distributes the voltage profile, and limits surface discharges. The ball-and-socket coupling facilitates assembly and maintenance, and the products are compatible with standard hardware, adapting to different working conditions such as tension strings and suspension strings.
The suspension insulators produced by Hejian Haokang Electric Co., Ltd. cover common disk-type suspension specifications, allowing different mechanical failing load ratings to be selected according to line load requirements. The product design focuses on the following points:
- High-strength porcelain body: The porcelain body is fired at high temperature, with a dense structure, high tensile strength, and good resistance to thermal shock.
- Anti-pollution shed profile: The shed dimensions and spacing are rationally designed to increase creepage distance and reduce the probability of pollution flashover.
- Reliable connection: Metal fittings and the porcelain body are firmly cemented, with standardized assembly dimensions and good interchangeability.
- Strong weather resistance: Suitable for outdoor rain, fog, temperature variations, and strong UV environments, and ideal for long-term operation.
| Main Items | Description |
| Product Name | Power line suspension insulator |
| Common Voltage Levels | 10kV, 35kV |
| Material | High-strength electrical porcelain |
| Structure Type | Disc suspension type |
| Connection Mode | Ball-and-socket or clevis type |
| Installation Method | Suspension string / tension string |
| Service Environment | Outdoor high-voltage lines |
| Custom Services | Specification selection available based on project |
In terms of technical specifications, the products comply with the insulation coordination requirements for the corresponding voltage levels. When selecting, comprehensive calculations should be made based on the line's nominal voltage, system grounding method, altitude, pollution class, and mechanical load. For example, in heavily polluted areas, the creepage distance should be appropriately increased; at high altitudes, the number of insulator units should be corrected considering air density; on large span or long crossing sections, the mechanical strength of insulators must be verified. Hejian Haokang Electric Co., Ltd. can provide technical communication with customers and recommend suitable solutions based on on-site working conditions, avoiding simple voltage-level-based selection and balancing safety and economy.
Hejian Haokang Electric Co., Ltd. has long supplied a wide range of line and station porcelain products, including glass insulators, FRP insulators, pin insulators, porcelain cross-arms, porcelain tension rods, spool insulators, strain insulators, and line post insulators, as well as indoor and outdoor post insulators, wall bushings, rod post insulators, and various electrical porcelain housings and components. The factory has a complete production process with quality control from raw material handling to finished product inspection. All products are shipped according to standards, and bulk ordering and logistics delivery are supported. Choosing direct factory supply can reduce intermediate links and also provide faster technical feedback and after-sales service.
If your project is planning the construction, renovation, or spare parts procurement of 10kV or 35kV lines, please feel free to contact us. Please provide information such as operating voltage, pollution condition of the line environment, tension or suspension configuration, and mechanical load requirements. We will help you determine the appropriate number of insulator units, creepage distance, and connection mode to ensure long-term stable operation of the line.
Frequently Asked Questions:
Q1: How many suspension insulators should be selected for 10kV and 35kV lines respectively?
Answer: The number of insulators is not determined solely by the voltage class; insulation coordination calculation also needs to consider the tower grounding method, altitude, pollution level, and flashover requirements. In conventional designs, 10kV lines usually require one to several pieces, and the number for 35kV lines will increase accordingly. Our company can provide reference solutions based on engineering parameters.
Q2: How to select suspension insulators according to the pollution environment?
Answer: In heavily polluted areas, products with larger creepage distance or optimized shed spacing should be selected. The specific creepage distance of the whole string can also be increased by adding more insulators; meanwhile, the self-cleaning performance of different shed profiles can be compared. The specific selection should be determined by referring to the local pollution area distribution map and operational experience.
Q3: What are the characteristics of suspension porcelain insulators compared with glass insulators?
Answer: Porcelain insulators have high mechanical strength, strong resistance to temperature variation, and can maintain a certain insulation performance even after the glaze is damaged; glass insulators self-shatter after breakage and are easy to detect during inspections. Each has its own applicable scenarios, and porcelain products still hold an important position in the renovation of old lines and in some heavily polluted heavy industrial areas.
Q4: How to choose between ball-and-socket and clevis connection methods?
Answer: The ball-and-socket connection is compact in structure and convenient to install when used with ball clevis fittings, adapting to most suspension and tension conditions; the clevis type connection is suitable for some old lines or special fittings. When selecting, ensure that the insulator steel pin, steel cap, and line fittings are dimensionally matched.
Q5: What should be paid attention to during the transportation and on-site storage of suspension insulators?
Answer: During transportation, avoid severe collision and squeezing, keep the packaging intact, and use forklifts or lifting equipment for loading and unloading. After arrival, they should be stored in a dry and ventilated warehouse, and should not be stacked outdoors for a long time, to prevent corrosion of metal fittings and moisture from affecting the cementing performance.
Q6: How to judge the quality of received suspension insulators?
Answer: A visual inspection can be conducted. The porcelain body should be free of cracks and glaze damage, and metal fittings should be free of deformation and corrosion. The cemented parts should be firm, and the rotation should be flexible without looseness. For batch deliveries, a qualified testing institution can be commissioned to carry out power-frequency voltage and mechanical load tests.
Q7: Can your company provide non-standard customized specifications?
Answer: Yes. Hejian Haokang Electric Co., Ltd. has the production capacity for various porcelain insulators. Customized connection dimensions, shed profiles, or special mechanical strength levels can be negotiated based on drawings or samples. However, for customized products, complete technical requirements must be provided and the production cycle confirmed.
