Product Spotlights
2. Intelligent control system, no manual adjustment required
3. Special movement for outdoor waterproof tower clock; stepper motor with high torque, energy saving and long service life
4. Automatic time calibration via GPS satellite, accurate and reliable timekeeping
5. Rich optional functions: automatic night lighting, hourly music chime
6. Remote monitoring, on/off setting via mobile phone
Related Products
-
Premium European Street Clock | Outdoor Post Clock for Hotels, Communities & PlazasNegotiableMOQ: 1 Unit -
European-style Vintage Outdoor Landscape Clock Black-and-gold Columnar Metal Pointer Numbers Illuminated Design Custom-madeUS$ 6000 - 8800MOQ: 1 Unit
-
European Style Landscape Clock Customized for Park Square Street Vertical Column Post Clock Glow-in-the-Dark World Time ModelUS$ 6000 - 8800MOQ: 1 Unit
-
Custom European Style Landscape Clocks Street/Campus/Park/Square Decorative Pillar Post Office Clocks Kts-15 NocturnalNegotiableMOQ: 1 Unit
-
Custom European Style Landscape Clock GPS/BD Large Clock for Parks Shopping Mall Entrances; Column Clock ChimeNegotiableMOQ: 1 Unit
Landscape Street Clock Functional Configuration Introduction:
1、Timekeeping: Fully microcomputer-controlled and managed, screen display, two-hand movement. The master/slave clock system uses closed-loop control to maintain synchronization between slave clocks and the master clock.
2、Movement: Uses Compas patented worm gear and worm drive movement, brass gears, other components use 45# steel quenched and tempered, adaptable to various harsh environments, durable. Uses stepper motor drive, high output torque. Movement service life up to 60 years.
3、GPS Satellite Time Calibration: Uses a computer center connected to satellite signal receiving equipment to compare and calibrate the extracted standard time with the master clock time, ensuring the tower clock operates synchronously with standard time, achieving no cumulative error.
4、lighting: high brightness LED energy-saving lamps lighting, opening and closing time automatically controlled by the system.
5、Automatic Memory & Automatic Time Catch-up Function: During AC power failure, the master clock automatically memorizes the time for up to 10 years. After power restoration, the slave clock can automatically catch up to the standard time, requiring no manual adjustment.
6、Synchronization Function for All Slave Clock Faces: When one slave clock face becomes unsynchronized with others, the control system automatically detects and adjusts it back to synchronization.
7、Anti-Interference Capability: Utilizes hardware and software measures such as watchdog design, software redundancy, and low-pass filtering in the design, featuring strong anti-interference capabilities.
8、Moisture Resistance: The entire unit features lightning protection, rainproof, moisture resistance, and good weather resistance.
9 、Power Supply: Voltage 220V ±10%, Frequency 50HZ ±2%, Power 1000W.
10、Safety Assurance Function: The entire system operates on a 12V DC safe voltage, providing effective safety assurance for the user.
11、Maintenance-Free Function: The entire tower clock system is reasonably designed, has a long service life, and requires no manual maintenance.
(III) Technical Parameters:
1、Master Clock (Control Cabinet), GPS Signal Reception Unit
(1) Ambient Temperature: -50℃ ~ +60℃
(2) Operating Environment Temperature: -30℃ ~ +60℃
(3) Relative Humidity: 30% ~ 95%
(4) Timekeeping Accuracy: ±0.04 seconds/day (no cumulative error)
(5) Interface Method: Standard RS-232
(6) Number of Interfaces: 4
(7) Power Supply: AC220V ±10% 50HZ
(8) Power Consumption: ≤20W
2、Slave Clock
(1) Ambient Temperature: -50℃ ~ +60℃
(2) Inherent Timekeeping Accuracy: ±0.1 seconds/day (no cumulative error)
(3) Torque: Greater than 98 Newton-meters
(4) Power Consumption: ≤25W
3、Chimes reporting power: 300W and four outdoor waterproof sound columns.
4、Service Life: Entire unit service life of 60 years.
5、Drive Method: Constant current chop plus subdivision.
6、Street Clock Power Consumption: ≤120W
