Help CenterSmall Wheel Loader
Related Products
Specifications
small wheel loader1. CE
2.chassis uses swing joint structure
3. diesel engine 385 direct ejection
small wheel loader
Model :ZL10
1) The chassis uses swing joint structure, whose turning radius is minor, which can turn flexibly ang is suitable to work in poky space
2)It adopts directly in ejections diesel engine 385 for power, which is start and consumes less oil, whose power is 20KW
Main Specification for ZL-10 | |
Item |
ZL10 |
Rated load(kg) |
1000 |
Bucket capacity(m3) |
0.5 |
Wheel distance(mm) |
1320 |
Axle-base(mm) |
2150 |
Loader clearance radius(mm) |
4700 |
Mini base to the ground(mm) |
230 |
Dump clearance(mm) |
2680 |
Distance acc.to the height(mm) |
800 |
Time of raise(s) |
4 |
Hydraulic cycle time(s) |
9 |
Turns to pick the strength mose greatly(kn) |
32 |
Drive ways |
four wheel drive |
Operating weight(kg) |
2500 |
Overall dimensions(mm) |
4800*1700*2550 |
Engine model |
Changchai 385 |
Engine rated power(kw) |
20. |
Engine rated output(rpm) |
2200.. |
