Specifications
1,sectional directional control valves: CDB & ZCDB series2,They are split-flow valve & non-split-flow valve, both with 1 to 6
sectional directional control valves,china hydraulic parts ,hydraulic machines
u They are split-flow valve & non-split-flow valve, both with 1 to 6 working sections,
u Valves capable of handling up to 80l/min; 100l/min with pressure 160bar, 200bar max pressure up to 250bar
u Selective operation methods: manual control: T (spring return) and W (ball locking)
u Joining port: L (screw connection)
u Selective spool functions: O, A, Y
u Oil circuit modes: parallel
u Nominal diameter: G3/8; G1/2; M22*1.5
u Model examples: CDB-L15F-OT; CDB-L15F-5OT; ZCDB-L15F-2OT-G1/2; ZCDB-L15-7OT—G1/2 etc.
1.FAQ>>About Delivery Term
Q…What’s the delivery term for making business with us?
A…Usually we send the shipments in FOB term.However,the terms of CIF and C&F are acceptable which depend of clients.
2.FAQ>>About Lead Time
Q…What’s the lead time after placing the order?
A…It takes about 15-30days after we received your confirmation.Howeve,it depends on our production line schedule and other force majeure that are out of our control.
3.FAQ>>About Payment Term
Q…What’s the Trade Term ?
A… FOB to your nearest seaport, as you require!
5.FAQ>>About material
Q...What is the material of your car lift ?
A...The main material is cast iron, steel !
6.FAQ>>About your company
Q...Are you a factory or trading company?
A...We are a factory !
