304 Tractor, Farming Tractor, Tractors Price (20HP 4WD Tractor)

304 Tractor, Farming Tractor, Tractors Price (20HP 4WD Tractor) thumbnail-1
304 Tractor, Farming Tractor, Tractors Price (20HP 4WD Tractor) photo-1
US$ 5,000 - 20,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Zhengzhou Dongfeng Mid-South Enterprise Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Other, Gear Drive, 4WD
Power(W) 30HP
Certificate EEC
Brand Name Dongfeng
Model Number 304
Place of Origin China
After-sales Service Provided Overseas service center available

Specifications

1, 20~50HP tractor EPA 4 approved
2, 16~50HP tractor EEC approved offer COC report
3, All OECD approved

304 tractor, 30hp 4wd tractor
-3 cylinder diesel engine
-6+2 Gearshift
-Single or dual stage clutch









Tractor

Parameters

Model

JM-304

Drive Type

4WD

Overall Dimensions

L*W*H(mm)

3230×1435×1985

Wheel  Track

(mm)

Front

1200

Rear

1150-1450

Wheel Bass(mm)

1833.5

Ground Clearance(mm)

292

Rated Traction Force(N)

6400

Construction Mass(kg)

1780

Min. Turning Radius(m)

4.2

Theoretical

Speed(km/h)

Forward

(creep)

2.248 3.008 4.217 6.258 10.37 13.875 19.451 28.867

Reverse

(creep)

2.861 13.2





Engine

Model

TY395

Type

3-Cylinder Vertical, Water Cooled, 4 Stroke Cycle

Rated Power(kw/hp)

22.1/30

Rated Speed(rpm)

2200

Bore×Stroke(mm)

95×105

Total Displacement(L)

2.23





Drive

System

Clutch

Dual-Stage

Gear Box

(4+1)×2

Main Drive

One Pair of Spiral Bevel Gearing

Differential

Bevel Gear

Different Lock

Jaw Lock

Final Transmission

Spur Gear, External Gearing



Traveling

Mechanism

Type

Front

7.5-16

Rear

11.2-24

Steering Gear

Full Hydraulic Steering

Brake

DiscType







Working Device





Hydraulic System

Lifting Capacity

at 610mm

Behind Lift Point(N)



4900

3-Point Suspension

Category:1

P.T.O

Shaft

Roating Speed(rpm)

540/720 or

540/1000

Spline Size

6-φ35Rectangular Spline

Options

Roll bar, Canopy, Shuttle, Hydraulic, Steering, Dual stage clutch,

Turf Tyer, Cab
