Specifications
1.PLC Control&Servo Motor2.High Capacity
3.Custom-Made For Different Bottles
Labeling Machine
Automatic two sides labeling machine
This machine is applied to label the self-adhesive label on various bottles
and containers. And it is widely used in pharmaceutical, foodstuff, beverage, cosmetic, chemical and etc. industries.
Specialty:
1.Automatically label 1 or 2 side, or label around bottles.
2.Adopting Germany SIEMENS PLC control unit
3.Adopting easy operation large touch sensitive screen
4.Adopting Germany label sensor
5.Adopting Japan object sensor
6.The machine body is SUS304 stainless steel and 6063 aluminum alloy structure.
7.Labeling head can deflex ±20o to suit for tapered bottles
8.Can be equipped with coding machine or printing machine, print clearly. (optional )
9.Such machine is multi-functions, it fit for round bottles, flat bottles, square bottles, oval bottles or
other shape products, only have some adjustment is ok.
10.High labeling speed and high precision
11.Can be operated alone or contract with the production line.
12.Such machine can label one circle around on the round bottles, and can locate label.
Technical data:
Standard model |
HL-3130F |
Label width(max) |
180mm |
Label length |
10-300mm |
Conveyer belt width |
101.6mm |
Diameter of bottle(max) |
Φ110mm |
Outside diameter of label roll(max) |
Φ350mm |
Inside diameter of label roll |
Φ76mm |
Labeling speed(max) |
21m/min |
Accuracy of labeling |
±1mm |
Overall size(L*W*H) |
3000*1400*1500mm |
