Raising Line Marking Machine
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
China
The raising line marking machine for raising line is applicable for entry and exit of highway, gyroidal gradients of viaduct and urban quick paths so as to remind the vehicls for speed reducing and decrease traffic accidents.
Main features of the liner machine:
- The marking machine shall be equipped with HONDA engine orignally imported from Japan and be started by LPG
- To form marking operation one-off through sensor system, air pressure system, propelled driving system etc.
- the raising gap can be adjusted according to requirement of different projects.
- Bead dispenser: auto-simultaneous-step clutch.
- The quantity of bead is adjustable.
Main technical parameters of the liner machine:
- Outer dimension: 1350x800x1050mm
- Total weight: 260kg
- Volume of spraying cylinder: 100kg
- Marking speed: ≥400m/h
- Upgrate angel: 18°
- Height of raised line: 3~8mm
- Height of basic line: 1.6~2.0mm
- Engine: Imported HONDA engine
- Power: HONDA GS5.5HP
- Spraying width: 150/200/300mm
- Spraying funnels with different size can be replaced as per requirement of different projects.
