Full Hd 1080P 16CH SDI DVR, Digital Video Recorder Standalone DVR Quality Choice

Full Hd 1080P 16CH SDI DVR, Digital Video Recorder Standalone DVR Quality Choice thumbnail-1
Full Hd 1080P 16CH SDI DVR, Digital Video Recorder Standalone DVR Quality Choice photo-1
US$ 597 - 602 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
enster
Model Number:
EST-9216-E
Contact Supplier Request Quote Chat Now
Shenzhen Enster Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name enster
Model Number EST-9216-E



Full Hd 1080P 8CH SDI DVR

videotape:16ch 1080P
playback:1ch 1080P
Audio frequency:16 in 1 out
Alarm: Into 16 out of 4
talkback:have
HDMI Export:have
E-Sata Export:have

Number of hard drives supported:8 pieces of 2T





Model 9216-E
System User Interface Graphic User Interface (OSD)
OS Embedded Linux
Operation Mode preview, record, playback, backup, network
Password Security Multi-level user management
A/V Input Video input 16 CH SDI Connector
Audio input 16 CH BNC Connector
A/V Output HDMI output Supports 720P,1080I,1080P,
1024X768,1280X1024, 1366X768,1440X900
VGA output Supports
Display 1/4 /9 optional
Video standard PAL/NTSC
Loop NO
CVBS main output 1CH, BNC connector
Spot output NO
Audio output 1CH,BNC connector
A/V encoding parameters Video compression H.264
Display frame rate PAL:400 fps(16 x 25 fps).NTSC:480 fps(16 x 30 fps)
Recording frame rate PAL:400 fps(16 x 25 fps)   NTSC:480 fps(16 x 30fps)
Video encoding resolution PAL:WD1:960*576/D1(704X576)/HD1(704X288)/CIF(352X288)/1080P(1920x1080)/720P(1280X720)
NTSC:WD1:960*480D1(704X480)/HD1(704X240)/CIF(352X240)/1080P(1920x1080)/720P(1280X720)
Video frame rate PAL: 1-25FPS NTSC:1-30FPS
Video bit rate 720P:1536kbps-3072kbps, 1080P:4608-6144kbps,(WD1)D1:768-1536Kbps,HD1:512-1280kpbs,CIF:384-768kbps,QCIF:192-384kbps
Stream Type Video & Audio/Video
Audio compression ADPCM
Recording mode Always/Schedule/Alarm recording/Motion detection recording
Video search Time/Channel/Event
Audio bit rate 32kbps
Dual-stream Supports
Mobile phone Monitor Supports Android phone/iPhone/iPad
Recording resolution 4 CH 1080P + 12 CH WD1 Recording+ 1CH 1080P (WD1) Realtime playback/16CH Playback(not realtime)
HDD Type 8 pieces SATA
Maximum capacity 2TB for each Sata connector
External connectors Voice talk Support, 1CH BNC line in/1CH BNC line out.
Record mode Audio & Video recording simultaneously
Remote control Supports
Mouse control Supports
Network protocol Supports IE/PPPoE/DDNS
Domain name server Support 88110,reelink,3322, dyndns, no-ip, changeip, dnsexit domain name server as default value.
Network  1 RJ45 10M/100M/1000M
Serial port 2 RS-485 serial port
E-SATA Connector Supports
USB Connector 2 USB
Firmware update Support USB update/Network update
Alarm input 16CH alarm input
Alarm output 2CH alarm output
Others Power supply ATX
Power (without HDD) ≤70 W
Operation Temperature -10°C--+55°C
Operation Humidity 10%--90%
Chassis Standard 2U
Dimension 435mm(W)×440mm(D)×90mm(H)
Weight(without HDD) ≤6Kg







....
