Hot Sale! Max 600m Depth! HF-3 Hydraulic 600m Depth Trailer Water Well Drilling Rig

US$ 1 - 50,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, well drilling

Power Type:

Diesel

Zhengzhou Hanfa Prospecting Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Shanghai Tianjin port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, well drilling

Power Type Diesel

Place of Origin Henan, China

Brand Name HF

Model Number HF-3

Usage Water Well

Voltage 220V/380V

Power(W) 31KW

Weight 8T

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

600m Depth Trailer Water Well Drilling Rig HF-3 drilling rig Specifications information

Drilling depth	m	600
Open hole caliber	mm	300
End hole caliber	mm	75
Drilling rod	mm	Φ60
Drilling angle		90°-65°
Spindle
Spindle forward speed	r/min	57-1024
Spindle reverse speed	r/min	45-212
Spindle stroke	mm	560
Spindle inner diameter	mm	96
Spindle lifting capacity	KG	6000
Hoist
Single line lifting speed	m/s	0.515 0.894 1.421 1.948
Hug floodgate belt width	mm	90
Tightrope caliber	mm	12.5 or 14
Hoist single line lifting capacity	KG	3000
Reel caliber	mm	200
Reel cubic measure	m	30
Mud pump
Horizontal double actuator
Displacement	L/min	200,125
Triangle conveyer belt type		B×5
Work pressure	Mpa	4.6
Water inlet caliber	mm	65
Water to exit caliber	mm	37
Oil pump
Duplex gear oil pump F532/F314
Front displacement,pressure		32L/min 20Mpa
Behind displacement,pressure		14L/min 20Mpa
Drilling rig Power
Diesel engine	Hp	4100 41HP
Electric motor	KW	Y180L-4 22KW
