GAVR-15A Universal Three Phase AVR Use for 150KW Alternator
unversal 15 Amp 1/2 Wave Self Excited Dip-Switch Progmmable avr
escription:In addition to rregulating the generator voltage,the avr circuitry includes under-speed and sensing loss protection features.Excitation power os derived directly from the generator terminals.
Positive voltage build up from residual level is ensured by the use of efficient semiconductors in the power circuitry of the avr/
The avr is linked with the main stator windings and the exciter field windings to provide closed loop control of the output voltage with load regulator of +/-1.0%.
In addition to being powered from the main stator,the avr also derives a sample voltage from the output windings for coltage control purposes.In response to this sample voltage,the avr controls the power fed to the exciter field,and hence the main field,to maintain the machine output voltage within the specified limits,compensating for load,speed,temperature and power factor of the generator.
Afrequency measuring circuit continually monitors the generator output and provides output under speed protection of the excitation system,by reducing the output voltage proportionally with speed below a pre-settable threshold.A manual adjustment is provide for factory setting of the under frequency roll off point,(UFRO).This can easilly be changed to 50 or 60Hz in the field by push on link selection.
Provision is made for the connection of a remote voltage trimmer,allowing the user fine control of generator's output.
Features
- Voltage Regulation < ±1%
- 220/440VAC Programmable Input
- Rugged Compact Desigh
- Soft Start Voltage Ramping
- With Under Frequency Roll Off Protection
- EMI Suppression
- Built-in High Capacity 15Amp Fuse
| Sensing input Voltage | 220/400VAC , 1 phase 2 wire |
| Power Input voltage | 180-240VAC , 1 phase 2 wire |
| Output voltage | max 90 VDC at 240VAC input |
| Current | Continuous 6A , intermittent 12A for 10secs |
| Resistance | Min.10 ohm , Max 100ohm |
| Voltage Build-up | residual voltage at avr terminal >5VAC |
| Voltage Regulation | <±0.5% with 4% engine governing |
| Operating Temperature | (-40°C to +65°C |
| Storage Temperatue | (-40°C to +85°C |
| External Volts Adjutment | ±7% with 1k ohm 1 watt trimmer |
| EMI Suppression | Internal electromagnetic interference filtering |
| Unit Power Dissipation | Max.8 watt |
| Under Frequency Protection | 60Hz system presets knee point at 57Hz |
| 50Hz system presets knee point at 47Hz | |
| Dimensions | 157mmL*117mmW*70mmH |
