Specifications
Bull nose medical oxygen regulatorAluminum body all brass inner core
Barb or DISS outlet
Output:50 PSI
- oxygen flowmeter
- origial factory OEM
- CE;ISO9001ISO13485
- Kind standards opional
A oxygen flow control regulator is a pressure-reducing device, which lowers the oxygen pressure from a cylinder to levels, which can be safely used by the patient. Oxygen Regulators are intended for the administration of oxygen to patients who need increased oxygen levels to improve their breathing conditions.
This oxygen regulator uses an advanced, patented Intelliflo disc to regulate oxygen flow down to 1/32 LPM with very tight tolerances. Featuring a brass core for maximum safety and permanent laser etchings on knob and body that won't peel, flake or wear off. All metal anodized aluminum construction is more durable than plastic and will not rust, plus the gauge protector helps prevent damage. Five-year warranty (excludes contents gauge and gauge protector). 1/2 to 15LPM Small Tank Regulator.
Specifications:
- Dimensions CGA540: L x O.D. => 5.5x 1.25" (140x 32mm)
- Weight CGA540: & 20oz (550gr.)
- Dimensions CGA870: L x O.D. => 6.0x 1.25" (153x 32mm)
- Weight CGA870: 20oz (550gr.)
- Materials: brass (core), anodized aluminum (body)
- Indicators: Cylinder contents, oxygen flow rate
- Relief valve pressure: 125 psi (862 kPa)
- Flow data: "OFF", 1/32, 1/16. 1/8, 1/4, 1/2, 1, 1.5, 2, 2.5, 3, 4 LPM
- Storage temperature: -40°F to 140°F (-40°C to 60°C)
- Operating temperature: 0°F to 125°F (-18°C to 52°C)
- Filtration: 66 micron
- Supply pressure: 250 to 2500 psi (1724 to 17,240 kPa)
- Operating pressure: 50 psi (345 kPa)
- Outlet connection: Barbed connector - 3/16" O.D. tubing
- Inlet connections: CGA540 or CGA870
Colors :can be anodized to green, red, silver, black, gold, brown, blue, purple
