Home > Health & Medicine > Medical Equipment > Ventilator > Hot Sell Oxygen Regulator DY-C8

Hot Sell Oxygen Regulator DY-C8

Name: Hot Sell Oxygen Regulator DY-C8
Brand: DengYue
SKU: 102569461

Hot Sell Oxygen Regulator DY-C8 thumbnail-1

US$ 10 - 10.3 MOQ: 500 Pieces

Key Specifications

Get Latest Price

Type:

Breathing Apparatus

Brand Name:

DengYue

Model Number:

DY-C8

Contact Supplier Request Quote Chat Now

Yuyao Dengyue Medical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ShangHai/Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Breathing Apparatus

Brand Name DengYue

Model Number DY-C8

Place of Origin Zhejiang, China

Specifications

Input pressurs:15mpa

Output Pressure:0.2mpa-0.3mpa

Fowmete Control Range:1L/Min-15L/min

Safety Valve:0.3mpa-0.05mpa

More details

1.All series have passed and CE certificate

2.The main part uses the goodness brass and cut with precision digitally controlled lathe

4.Integrated casting flowmeter

5.Flow tube ,wet cup of high-pressure sterillized Humidification body to meet European standards for B-level disinefection .

6.The maximunm temperature of 121 degree pressure 0.142mpa

Attention

1.Make sure there is on ash on the connector and check the screw thread, then install the inhalator

2.Make sure the flow meter is vertical to the floor and flow regulating valre is closed,then Open the valve of oxygen cylinder slowly,regulate the flow after the high pressure gavge shows the pressure of the oxygen cylinder .

3.No drestic shock,for away with the corrsive substance and no oil stain .

4.The set screw of the safety valve can't be rotated at randon,non-professional people are forbidden to dismount .

Condition for strage

shoule be kept in the environmen whose humidity is less than 90% no corrosive gas and drafty.

gas inlet types:

1.gas -specific inlet probe conforming to BS ,AMERICAN, GERMAN, FRENCH

2.1/8'' NPT female-threadde inlet

3.Bullnose nipple with 3/8'' BSPNUT. Other country-specific direct and remote-fitting configurations are

available- contact the office.

gas outlet types:

1.body has female thread -use BMI 'universal'tubing nipple

2.body has a 9/16'' UNFmale thread -use tubing nipple(oxygen)

mounting:

1.direct-probe fits into wall-mounted gas -specific socket(antirotation device maintains flowmeter upright)

2.remote-kit available with 2m colour-coded flexible hose,and a gas-specific connector the flowmeter is mounted

remotely from the gas source on:

a)wall/machine-mouted V-plate

b)medical rail.

NOTE:the rail-mounting kit utilises a "universal' rail clamp,allowing attachment to BMI,ohmeda,vickers"modura",

din rail section.

operation and use

2.service & maintence

do dot disassemble when connected to a source of pressure

caution

repairs must only be undertaken by suitably trained personnel.

the pre-use checks in section 2, and the leakage check in section 3.2 must be carried out after any disassembly

3.tube assembly

outer tube

if the cover tube is cracked, withdraw the unit from service and renew:

1.disconnect the flowmeter from the pressure source

2.open the flow control valve to relieve any contained pressure.

3.hold the unit vertically (to retain the flow tube and ball )unscrew the cover tube and lift off.

calibrated tube and indicator ball

4.lift off the flow tube , taking care not to let the ball roll out

5.remove the tube connector adaptor and the cover tube o-ring

a new cover tube o-ring at the base of the body.

a new tube adaptor. Check orientation,as illustrated.

the flow tube , and ball over the adaptor.

9.position the tube with the scale towards the front of the unit.

the outer tube,and screw clockwise into the flowmeter body.

4. environmental conditions

store/operate between 5 and 25 degree

protect exposed o-rings from light

We have our own factory. We can manufacture medical products according to your requirement or your sample, drawing, and the quality is not less than your samples. If you provide us your sample, we could manufacture them and send our samples to you without charge to let you see our quality of our products.

We have been registered as a qualified enterprise of import-export operation. It is convenient to export products. Also, the price of material is greatly decreasing. So our the cost of processing, manufacturing is very competitive.
