Rotary Vane Wheel Dry Dial Iron Water Meter LXSG--15E~50E
US$ 1 - 5
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Tongqiu
Model Number:
LXSG-15E~50E
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Rotary Vane Wheel Wet Dial Iron Water Meter LXS--15E~50ENegotiableMOQ: 500 Pieces -
Rotary Vane Wheel Liquid-sealed Water Saving Type Water Meter LXSJ-15E~50ENegotiableMOQ: 500 Pieces
-
Rolling Wing Vertical Cock Water MeterUS$ 5 - 50MOQ: 1000 Pieces
-
DN 15MM Dry Dial Brass Class B Water Meter PriceUS$ 5 - 15MOQ: 1000 Pieces
-
Kent Brass Body Dry Dial Water Meter LXSG-15A2US$ 5 - 15MOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
Tongqiu
Model Number
LXSG-15E~50E
Features :
The mechanism of the register shall be selfhoused in the container of the corrosion resistant metal,with dry dial,straight reading,and rotation of the wheel be driven with magnet to the register,the case of water meter is made of cast copper and is beautifully shaped, Easy for reading, clearness and long service are its advantages.
Working Condition :
Water temperature: ≤40℃ pressure: ≤1Mpa
INDICATING ERROR:
At low zone is ±5% from minimum flow rate(qmin) to transitional flow rate(qt) exclusive boundary ;
At high zone is ±2% from transitional flow rate(qt) to overload flow rate(qs)
| Type | Meter size Dia DN (in.) | Class | qs Overload Flow | qs Nominal Flow | qs Transitional Flow | Qmin Min Flow | Min Reading Lectura | Max Reading Lectura |
| m3/h | 1/h | m3 | ||||||
| LXSG-15 | 1/2" | A | 3 | 1.5 | 150 | 60 | 0.0001 | 9999 |
| B | 120 | 30 | ||||||
| LXSG-20 | 3/4" | A | 5 | 2.5 | 250 | 100 | 0.0001 | 9999 |
| B | 200 | 50 | ||||||
| LXSG-25 | 1" | A | 7 | 3.5 | 350 | 140 | 0.0001 | 9999 |
| B | 280 | 70 | ||||||
| LXSG-32 | 11/4" | A | 12 | 6.0 | 600 | 240 | 0.0001 | 9999 |
| B | 480 | 120 | ||||||
| LXSG-40 | 11/2" | A | 20 | 10 | 1000 | 400 | 0.001 | 99999 |
| B | 800 | 200 | ||||||
| LXSG-50 | 2" | A | 30 | 15 | 4500 | 1200 | 0.001 | 99999 |
| B | 3000 | 450 | ||||||
| Type | Length | Width | Height | Connecting D(d) | Weight (Kg) |
| mm | |||||
| LXSG-13 | 165 | 99 | 104 | G 3/4B(R1/2) | 1.35 |
| LXSG-20 | 190 | 99 | 107 | G 1B(R3/4) | 1.45 |
| LXSG-25 | 225 | 99 | 112 | G1 1/4B(R1) | 1.9 |
| LXSG-32 | 230 | 104 | 112 | G1 1/2B(R11/4) | 1.9 |
| LXSG-40 | 245 | 125 | 145 | G 2B(R11/2) | 4.4 |
| LXSG-50 | 300/280 | 125 | 150 | G2 1/2B(R2) | 8.4/8.1 |
