CE Certified Linear Guide Way Vertical Machining Center

Name: CE Certified Linear Guide Way Vertical Machining Center
Brand: DALIAN
SKU: 102715049

US$ 34,780 - 108,060 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Vertical

Place of Origin:

Liaoning, China

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Vertical

Place of Origin Liaoning, China

Brand Name DALIAN

Model Number VDL600A VDL1000 VDL1200 VDL1400A

Certification CE Certificate; ISO9001:2008; GB/T19001:2008

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

Vertical Machining Center

There are four series of CNC machining center in our company:

CNC Horizontal Machining Center, CNC Vertical Machining Center, CNC High-speed Vertical Machining Center and CNC Milling Machine

CNC Vertical Machining Center: VDL500;VDL600A;VDL800;VDL1000;VDL1200; VDL1400A;VDF850 ;VDF1000; VDF1200; VDF1500; VDF1800

VDF series: Box way

VDL series: X/Y-Linear way, Z-box way;

CE Certificate is provided.

Item	VDL500	VDF850	VDL1000 VDF1000	VDL1200 VDF1200	VDL1400A	VDF1500	VDF1800
Table(L×W)(mm)	700×320	1000×500	1120×560	1220×620	1450×620	1700×800	2000×800
T-slot(Numbers×Width×Distance)	3×14×110	5×18×100	5×18×100	5×18×100	5×18×100	6×18×125	6×18×125
Table load Max(kg)	150	500	750	1500	1500	2500	2500
X/Y/Z rapid traverse speed(m/min)	30/30/30	20/20/18	24/24/18	24/24/18	24/24/18	15/15/12	15/15/12
Feed rate(mm/min)	1~10000	1~7600	1~10000	1~10000	1~10000	1~6000	1~6000
Spindle speed range(r/min)	60~10000	60~8000	60~8000	45~6000	45~6000	45~6000	45~6000
Tool magazine capacity/Type	12/drum	20/drum 24/swing arm	20/drum 24/swing arm	24/swing arm	24/swing arm	24/swing arm	24/swing arm
Tool adaptor type	BT40	BT40	BT40	BT50	BT50	BT50	BT50
Max. Tool weight(kg)	6	7	7	15	15	15	15
Time of tool change(T-T)(sec)	6~8	6~8/3	6~8/3	3.5	3.5	3.5	3.5
Air pressure requirement (MPa)	0.6	0.5	0.6	0.6	0.6	0.6	0.6
Power requirement (kW)	15	25	25	35	35	40	40
