Help CenterGantry Five Axis CNC Milling Machine, 3,000x2,000x800mm Capacity, 30kW Spindle, Designed for Mold and Die Industry
Product Spotlights
Related Products
-
Precision Five Axis CNC Milling Machine, 12,000rpm BT40 Spindle, 220V, Standard Compliant With 3-Year WarrantyNegotiableMOQ: 1 Unit -
Five Axis CNC Milling Machine 1,200x800mm Worktable, 15kW Spindle Power, CE Compliant for Precision MachiningNegotiableMOQ: 1 Unit
-
Five Axis Vertical Machining Center, 800x600x500mm Working Area, 12-Station Tool ChangerNegotiableMOQ: 1 Set
-
Five Axis Milling Machine With 2-Year Warranty and Free Installation Training, Mill Test Report IncludedNegotiableMOQ: 1 Set
-
Five Axis Milling Machine for Aerospace Impeller and Blisk Manufacturing, 5μm PrecisionNegotiableMOQ: 1 Set
As a leading supplier from Suzhou Excellence Intelligent Technology Co., LTD, we present our latest Gantry Five Axis CNC Milling Machine with a 3,000×2,000×800mm working capacity and 30kW spindle, specifically engineered for the mold and die industry. With over a decade of expertise since 2013 and an ISO9001-certified manufacturing process, our machines deliver the rigidity, precision, and reliability demanded by complex cavity machining. This solution is designed to reduce cycle times while maintaining tight tolerances, giving you a competitive edge in producing high-quality molds, dies, and large structural parts.
Key Features & Advantages:
- Robust Gantry Structure: Heavy-duty cast iron bed and reinforced crossbeam provide exceptional vibration dampening and thermal stability, ensuring long-term accuracy even under heavy cutting loads.
- 30 kW High-Torque Spindle: Capable of both roughing and finishing operations on hardened steel, aluminum, and composite materials. Optional spindle speeds up to 20,000 rpm for finer surface finishes.
- True 5-Axis Simultaneous Machining: Equipped with a tilting rotary table (A/C axis) for complex undercuts, angled features, and freeform surfaces common in mold and die work. Reduces setups and improves overall efficiency.
- Large Working Envelope: With X-axis travel of 3,000mm, Y-axis of 2,000mm, and Z-axis of 800mm, this machine accommodates oversized molds and multi-cavity dies in a single clamping operation.
- High-Precision Linear Guides & Ball Screws: All axes employ pre-tensioned double-nut ball screws and class C3 ground ballscrews, complemented by high-rigidity roller linear guides for smooth motion and repeatability within ±0.005mm.
- Advanced Control System: Compatible with industry-leading CNC controllers (Fanuc, Siemens, Heidenhain) upon request, offering 5-axis interpolation, tool radius compensation, and collision avoidance software.
- Automatic Lubrication & Chip Management: Centralized lubrication system reduces maintenance downtime, while dual spiral chip conveyors and a coolant flush system ensure efficient chip removal from deep cavities.
- Thermal Compensation Technology: Built-in temperature sensors and compensation algorithms maintain accuracy during prolonged machining sessions, critical for die-sinking and injection mold production.
Technical Specifications:
| Parameter | Value |
|---|---|
| Table Load Capacity | 8,000 kg |
| Rapid Traverse (X/Y/Z) | 24 / 24 / 20 m/min |
| Positioning Accuracy (VDI 3441) | ±0.008 mm (full travel) |
| A/C Axis Rotation Range | A: ±120°, C: 360° |
| Tool Interface | HSK-A63 / BT-40 (optional) |
| Cutting Feed Rate | 0–18,000 mm/min |
Why Choose Our Gantry 5-Axis CNC Milling Machine?
- Proven Performance in Mold & Die Applications: Our machines are trusted by manufacturers in North America, Europe, and Southeast Asia for producing injection molds, blow molds, stamping dies, and automotive components.
- Reduced Setup Time: Five-axis capability eliminates multiple fixturing steps, allowing complex geometries to be machined in one go – saving up to 40% in lead time for typical mold jobs.
- Enhanced Surface Finish: The combination of a rigid structure and high-speed spindle (with optional coolant through spindle) delivers mirror-like finishes on hardened steel (up to HRC 62).
- Global Support Network: With annual export value between USD 5-10 million and shipping ports in Shanghai, Ningbo, Shenzhen, and Qingdao, we ensure timely delivery and after-sales support across all major markets.
Trust & Reliability from Suzhou Excellence Intelligence
Since our establishment in 2013, Suzhou Excellence Intelligent Technology Co., LTD has been dedicated to supplying high-end CNC machining solutions. Our factory spanning 3,000–5,000 square meters operates under an ISO9001 quality management system, ensuring each machine undergoes rigorous inspection before shipment. We have successfully served clients in 14+ markets globally, from Western Europe to South America, and we continue to innovate based on real-world feedback. This gantry five-axis milling machine represents our commitment to delivering cost-effective, high-performance solutions for the most demanding mold and die challenges. Contact us today to discuss your specific requirements, request a quote, or schedule a factory visit. Our experienced engineers are ready to tailor the machine with custom control options, chip conveyor configurations, or additional automation solutions to match your production needs.
Frequently Asked Questions (FAQ):
Q1: What materials can this machine process?
A: It is designed to handle a wide range of materials including tool steels (H13, D2, S7), pre-hardened steels, stainless steel, aluminum alloys, copper, graphite, and composites. The 30kW spindle provides sufficient torque for heavy roughing cuts in hardened materials.
Q2: Which CNC control systems are available?
A: We offer several options including Fanuc 0i-MF+, Siemens 828D / 840D sl, and Heidenhain TNC 640. Customization is available upon request based on your programming preferences and post-processor needs.
Q3: How long is the delivery time?
A: Typical lead time is 45–60 days after order confirmation, depending on configuration and current production schedule. We also offer expedited options for urgent projects.
Q4: What after-sales support do you provide?
A: We provide remote troubleshooting via video call, on-site commissioning assistance (travel costs additional), and a one-year warranty on spindle and drive components. Spare parts are available from our warehouse in Suzhou.
Q5: Can the machine be customized for specific part sizes?
A: Yes, we offer customizable Z-axis clearance (up to 1,000mm) and extended X-axis travel (up to 4,000mm) for oversized molds. Please provide your workpiece dimensions for a tailored solution.
Q6: What is the minimum order quantity (MOQ)?
A: The MOQ is 1 unit for standard configurations. However, we offer discounts for multiple machine orders or repeat customers.
Q7: How is the machine packed for export?
A: Each machine is carefully packed with anti-rust wrapping, wooden crating, and reinforced bracing. We comply with international container shipping standards to ensure safe transit.
Q8: Do you have a video demonstration or test cut samples?
A: Yes, we can provide video recordings of actual test cuts on similar mold parts. Contact our sales team to request relevant footage or arrange a live demonstration at our factory.
