Help CenterStationary Type Home Elevator Lifts / Handicapped Wheelchair Lift for the Disabled and the Elderly
Related Products
-
Domestic Elevator for the Disabled and the Elderly/electric Lift for the DisabledUS$ 3,500 - 5,000MOQ: 1 Set -
Home Hydraulic Lift Home Use Hydraulic Cheap Home Lift for Disabled PeopleUS$ 3,500 - 5,000MOQ: 1 Set
-
JINCHUAN High-tech Vertical Wheelchair Lift/home Lift/disabled Lift MillUS$ 5,484 - 5,485MOQ: 1 Set
-
JINCHUAN Best Price Electric Hydraulic Disabled One Floor Lift 1.5-3mUS$ 5,484 - 5,485MOQ: 1 Set
-
Disabled Wheelchair Lifts For Home /disabled Hydraulic Lift ElevatorUS$ 5,484 - 5,485MOQ: 1 Set
Drive system: Two chain hydraulic operated systems available.
Height of Platform Lift
Height of lifts may be from a few steps, to three floors.
Number of stops – up to three.
Roll-on Access
Access to the platform is typically either a fixed access ramp, or optional ramp for applications where there is no pit.
Call Buttons
Call Buttons may be mounted in gate frame, surface mounted on wall, or flush mounted into the wall.
Safety Features:
There are multiple safety features built into each lift. The under-platform sensor detects when an object is blocking the lift’s path, helping to prevent damage to the item or lift.
Remote controls with key lock to prevent unauthorized access.
Platform controls use a constant pressure rocker switch, with key operation, emergency stop, and alarm buttons.
High guard panels with grab rail.
| Raised height | 1500 mm | |
| Lowered height | 100 mm | |
| Speed | 60 mm/s | 2.4 in/s |
| Power output | 1.5kw | |
| Power input | 220V/50HZ/25A | |
| Rated Loading Capacity | 50-350kg | |
| Drive System | Hydraulic | |
| Material of Platform | Powder Spraying or Stainless steel | |
| Load capacity | 350 kg | 770 lbs |
| Platform Size(LxW) | 1200*1000 mm | 47 x 40 in |
| Operation Panel | Polished Stainless steel(Up Down and Emergency Stop) | |
| Working Condition | Both indoors and outdoors | |
| Working temperature | From -20°~60°C | |
| Non-pit installation | directly fixed to concrete floor | |
| Control Device | Calling box and remote controller | |
Products Photoes :
