2016 nes Tyre recycling/used tyre retreading machines/Waste tyre production line
- Component
Vulcanizing tank
Circular guiding rail frame
Inflatable tyre grinding machine
Rubber powder collecting tank
Inflatable tread pressing machine
Rim disassembling machine
Envelope disassembly machine
Buffer strip extruder
Rubber cement mixing tank
Multifunctional tire repairing machine
1.Vulcanizing tank
Name |
Size(Diameter*length) |
Quantity of tyre |
|
1.5*1.5 M |
four tyres |
|
1.5*2M |
six tyres |
|
1.5*2.5M |
eight tyres |
|
1.5*3M |
ten tyres |
|
1.5*4M |
twelve tyres |
|
1.5*5M |
sixteen tyres |
Function |
Tyre preheating for vulcanization with wind cooling cycle motor |
|
|
Power |
30kw-90kw |
|
|
Heating way |
Electricity heating, guiding oil heating, steam heating |
|
2.FXM-C Inflatable tyre grinding machine FXM-C
Name |
Inflatable tyre grinding machine |
Model |
FXM-C |
|
Specifications |
15",16",20",22.5" |
|
Outside size |
1.6*1.8*2.1M |
|
Weight |
1150KG |
|
Technical parameter |
1.grinding head motor power: 11KW |
|
2.Rotation tyre matching power: 2.2kw |
|
3.Grinding head of left and right matching power: 0.55kw |
|
4.Grinding head of front and back matching power: 0.37kw |
|
Function |
1.For tyre rough surface radian grinding |
|
2.Equipped with tyre shoulder side polishing and tyre explosion-proof function |
3.Rubber powder collecting tank
Name |
rubber powder collecting tank |
Model |
FXM-B |
|
Outline dimension |
1.6*0.78*2.0M |
|
Weight |
220kg |
|
Technical parameter |
ventilation motor: 3kw |
|
Function |
1.For absorption of waste soo and smoke after grinding of tyre grinding machine |
|
2.Large capacity, smoke dust collection, convenient collection, energy-saving and health |
4. Inflatable tread pressing machine
Name |
Inflatable tread pressing machine |
Model |
FTT-B |
|
Specification |
15",16",20", 22.5" |
|
Weight |
850kg |
|
Technical parameter |
1.Press roller matching power: 0.55kw |
|
2.Press wheel matching power: 0.37kg |
|
Function |
For carcass and tread tire inflation pressing with explosion-proof function |
5. Rim disassembling machine
Name |
Rim disassembling machine |
Model |
LJC-A |
|
Specification |
15",16",20", 22.5" |
|
Outline size |
1.5*1.3*0.8M |
|
Weight |
100KG |
|
Function |
For disassembling of rim |
6. Envelope disassembly machine
Name |
Envelope disassembly machine |
Model |
LJJ-A |
Specification |
15",16",20",22.5" |
|
Outline size |
2.2*1.5*1.6M |
|
Weight |
350KG |
|
Function |
For envelope disassembly before and after tyre vulcanization, applicable to many kinds of tyre
|
7.Buffer strip extruder
Name |
Buffer strip extruder |
Model |
LJJ-A |
|
Specification |
20kg/h |
|
Outline size |
1.0*0.5*0.9M |
|
Weight |
80KG |
|
Power |
1.5KW |
|
Function |
Necessary equipment for tyre retreading process |
8.Rubber cement mixing tank
Name |
Rubber cement mixing tank |
Model |
XJB-B |
|
specification |
100L |
|
Outline size |
0.8*0.85*1.5M |
|
Weight |
130kg |
|
Technical parameter |
Power : 1.5KW |
|
Function |
Manufacturing of glue adhesion for carcass and tread with uniformity character, equipped with explosion-proof motor which can prevent fire
|
9.Multifunctional tire repairing machine
Name |
Multifunctional tire repairing machine |
Model |
TXT-A |
|
Specification |
15",16",20",22.5" |
|
Outline size |
1.2*1.0*1.5M |
|
Weight |
100KG |
|
Technical parameter |
Motor: 0.18kw |
|
Function |
Suitable for light grinding of tyre and equipping with lifting function during rubberizing |
