Energy Saving Complete Mini Cement Plant
1. Raw materials
The main raw materials used in the cement manufacturing process are limestone, sand, shale, clay,
and iron ore. The main material limestone is usually mined on site while the other minor materials may be mined either on site or in nearby quarries. Another source of raw materials is industrial by-products. The use of by-product materials to replace natural raw materials is a key element in achieving sustainable development.
2. Raw material preparation
Mining of limestone requires the use of drilling and blasting techniques. The blasting techniques use
the latest technology to insure vibration, dust, and noise emissions are kept at a minimum.
Blasting produces materials in a wide range of sizes from approximately 1.5 meters in diameter to
small particles less than a few millimeters in diameter. Material is loaded at the blasting face into
trucks for transportation to the crushing plant. Through a series of crushers and screens, the limestoneis reduced to a size less than 100 mm and stored until required.
Depending on size, the minor materials (sand, shale, clay, and iron ore) may or may not be crushed
before being stored in separate areas until required. professional cement plant manufacturer
3. Crushing and Pre-homogenization
During producing Concrete, most of the raw materials must be first crushed before being used to
make concrete. These rawmaterials include lime stone, clay, iron ore and coal, etc. The lime stone is of the greatest usage to make concrete. With comparatively larger particles and higher hardness,
crushing the lime stone to required fineness after mining is of relatively important consequence
among crushing all those raw materials. There are many crushers used in crushing these raw materials, such as jaw crusher, impact crusher, cone crusher and vertical shaft impact crusher, etc. According to the raw materials' different particles and hardness, there are several suitable crushers which can
be used in the crushing.
4. Grinding
Grinding is the last process of cement produce and the most current consuming working procedure.
Cement clinker get grinded into powder in right size. The smaller the particle size is, the better the final cement is. It's important to choose
suitable grinding machine.
5. Flow chart for reference
The equipments we use in this whole cement plant are vibrating feeder, fine crusher, bucket elevator, silo, belt conveyor, cement ball mill, bag filter, air classifier, auto packing machine and so on.
All the necessary equipments in this line can be provided by our factory.
We have cement production line experts to design specific solutions for your preference.
PXJ fine crusher
Bucket elevator
Belt conveyors
Grinding ball mill and air classifier
Bag filter
Auto packing machine
Cement ball mill working site
Batching bin
Rotary kiln
