Big Drum Semi-automatic Filling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Chemical, Food, Medical
Packaging Type:
Bottles, Cans, Capsule, Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Industrial Basket MillNegotiableMOQ: 1 Set -
Pigment Paint Coating Ink Production Basket MillNegotiableMOQ: 1 Set
-
Shell Tube Heat ExchangerNegotiableMOQ: 1 Set
-
Spiral Plate Heat ExchangerNegotiableMOQ: 1 Set
-
Industrial Double Planetary Mixer With Disperser for Lithium Battery Slurry DPM-2LNegotiableMOQ: 1 Set
Condition
New
Application
Beverage, Chemical, Food, Medical
Packaging Type
Bottles, Cans, Capsule, Cartons
Packaging Material
Glass, Metal, Plastic
Automatic Grade
Semi-Automatic
Driven Type
Electric
Voltage
220V/380V
Power
customized
Place of Origin
Jiangsu, China
Brand Name
Nganyin
Model Number
SFM
Certification
ISO
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
Big Drum Semiautomatic Filling Machine adopts gravimetric method to measure ,by weighing sensor output signal to control the charging valve opening, so as to realize the purpose of automatic filling. By equipped with a pump in the front end of the feeding port,or pressuring the material tanks to sent material from tank to the filling machine. The filter device can be added before filling to guarantee the quality of products.It is widely used in industries such as coating, printing ink, paint, asphalt, glue, lubricant, petrochemical, fineness chemical etc.. It is not only suitable for the filling of liquid, but also for filling of ointment product.
Technology Parameters:
| Model | Power Supply | Air Source (Mpa) |
Filling Range (kg) |
Filling Speed (Can/min) | Division Value (g) |
Material | Barrel Spec (mm) |
Filling Accuracy (kw) |
Roller Height (mm) | Gland Way |
| SFM-300 | 220V, 50HZ |
0.5 | 50-300 | 40-60 | 100 | Material Contact SS304 Stainless Steel |
≤Ø600*930 | ≤±100 | ||
| SFM-1000 | 220V, 50HZ |
0.5 | 200-1000 | 10-20 | 100 | Material Contact SS304 Stainless Steel |
≤Ø1000*1100 | ≤±200 |
