Specifications
Support 3DSupport deep color 24bit,30bit, 36bi
Support 24/50/60fs/HD-DVD/xvYCC
FEATURES
lOne MINI DP signal input converter and split to two HDMI signal output.
lSupport 3D
lSupport deep color 24bit,30bit, 36bit
lSupport 24/50/60fs/HD-DVD/xvYCC
lDigital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
lSupport signal retiming
lSupport output up to 20metres AWG26 HDMI standard cable length
lNo loss of quality
lInstalls in minutes
lNeed DC5V/1A power supply
SPECIFICATIONS: HDCN0005M1
Input and output resolution….……… 24/50/60fs/1080P/1080i/720p/576p/576i/480P/480i
Support video color format …………………………..………… 24bit,30bit,36bit deep color
Support audio format…………… DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
Max bandwidth…………………………………………………………………………. 225MHz
Max baudrate……………….…….………………….………………………………. 6.75Gbps
Input/Output TMDS signal ………….…………………………..…….. 0.5~1.5Volts p-p(TTL)
Input DDC signal ……………………………………………..………….…. 3.3Volts p-p (TTL)
Output DDC signal ……………………………………………..…………….. 5Volts p-p (TTL)
Output cable distance…………………………..……... ≤15m AWG26 HDMI standard cable
Max working current……………………………………………………………….…….. 600mA
Power adapter format..Input: ……........ AC (50HZ, 60HZ) :100V-240V; Output: DC 5V/1A
Operating Temperature range……..…………….……………………………….. (0 to +40°C)
Operating Humidity range………………………….….…… 5 to 90%RH (No Condensation)
Dimension (L x W x H) ……………………………….…………………… 68x51.6x16 (mm)
Weight…..………………………………………………………..…….…………………….. XXg
