Help CenterKTC-series Mold Temperature Controller
Related Products
-
Small Industrial Cooling TowerNegotiableMOQ: 1 Set -
CE KTC-Series Mould Temperature ControllerUS$ 1,000 - 2,500MOQ: 1 Unit
-
CE Export Type Price Digital Temperature Controller for SaleUS$ 1,200 - 9,240MOQ: 1 Set
-
New Condition Price Digital Temperature Controller With TimerNegotiableMOQ: 1 Set
-
Mould Temperature ControllerNegotiableMOQ: 1 Set
Feature:
Low oil protection and indication
Overheat protection and indication
Circulating pump overload protection and indication
Abnormality alarm buzzer and indication
Phase failure protection
Model |
KTC-1 |
KTC-2 |
KTC-3 |
KTC-4 |
||
Max. Temp.(°C) |
120°C |
95°C |
150°C |
200°C |
||
Diathermanous Media |
Heat transfer oil |
Water |
Heat transfer oil |
Heat transfer oil |
||
Heating Energy(KW) |
6 |
6 |
9 |
9 |
||
Cooling Type |
Indirect |
Direct |
Indirect |
Indirect |
||
|
Pump
|
Motor Power |
1HP |
1HP |
1HP |
1HP |
|
Max. Pressure |
4kg/cm |
4kg/cm |
4kg/cm |
6kg/cm |
||
Max. Flow |
60L/min |
60L/min |
60L/min |
60L/min |
||
Power Supply |
220V/380/415V 60HZ/50HZ |
|||||
Oil Tank Volume |
8L |
8L |
8L |
8L |
||
|
Pipe Dia.
|
Circulating System |
2×1/2 |
2×1/2 |
2×1/2 |
2×1/2 |
|
Cooling System |
1/2″ |
1/2″ |
1/2″ |
1/2″ |
||
Overall Dimendsions |
650×280×700(W*D*H) |
|||||
Weight(kg) |
60 |
60 |
60 |
70 |
||
MTC-series:
We use PE plastic film, Plywood cases, wooden cases or as your request.
Guangzhou Jiayin Machinery Pte., Ltd (privite name:Guangzhou Mikasa Machinery Pte., Ltd) is one of
the pioneers in auxiliary plastic forming equipment industry in China, specializing in research design, manufacture and distribution and service of such equipment with the technology and experience accumulated over 20 years. To View more information about us, please back to our home page.
Our factory:
Pre-sales and After-sales Service:
We provide pre-sales and after-sales consultation and technical guidance. Welcome to contact me anytime.(Contact information as per the bottom of the page)
Guarantee:
One year warranty(except atificial damages). Within the guarantee period, we will offer customers spare parts free of charge if spare part is broken and the problems caused by our quality. (The freight is for buyer's account)
Installation:
We provide technical guidance, and also we can offer our technical engineer to buyer's factory for installation, if buyers
require. Ticket, board, lodging and some related local expenses in Buyer's country are borne by buyer.
-- Do you provide customizing service?
-- We can make products according to customer's requiments.
-- What is the voltage?
-- 380V 50hz 3 phase.(we can change it according to customer's requirement, charging fees)
If any more information you want to know, please contact me freely.
