Main performance & Characteristics:
- Use PLC programmable system, pneumatic control system and color touch screen to form the control center, can random adjusting capping speed.
- Machine use stainless steel (316/ 304) for excellent durability and sanitation compliance, the whole machine designed according to GMP standard, easily to disassemble and clean.
- Machine adopting world famous brand electrical elements to ensure the quality and stability.
- No need to change any components, easy to realize changing the cap types by simple adjusting.
Technical Parameters:
Capping Wheel |
One wheel |
Suitable cap diameter |
40mm ~ 80mm (capping wheel is made to order) |
Suitable bottle height |
240mm ~ 500mm |
Capping speed |
3,000 bottles/ hour |
Working Voltage |
220V/ 380V AC (Or according to customer voltage requirement) |
Power |
1KW |
Air Pressure |
0.50~0.70Mpa |
Material |
Stainless Steel 316 & 304 (upon request) |
Dimension |
(L) 2000mm x (W) 1100mm x (H) 2200mm |
Weight |
500 Kg |
Country Origin |
China |
Suitable samples:
Electical parts:
- PLC control system: Mitsubishi/ Japan
- Touch screen: TouchWin color screen/ Canada
- Solenoid valve: AIRTAK/ Taiwan
- Cylinder: AIRTAK/ Taiwan
- Air source treatment: AIRTAK/ Taiwan
- Electro-optical system: Omron/ Japan
- Main Electrical elements adopt international famous brand
1. Technicial guidance;
2. Able to provide video for debugging;
3. Pre-maintance;
4. Quality guarantee for 1 year. Able to send engineer to dubug/ maintance. (Hotel & delivery fee paid by customer);
5. You are welcome to share us the sample to test machine;
