Specifications
Cap Closing Machineone closing head,closing 3000b/h,cap dia.28-72mm
closing plastic cap,closing head can be customerized
Technical performance of this capping machine:
The capping machine is designed on the basis of the diversity of the capping requirements home and abroad which has stronger generability.
This capping machine has properties of reliable and stable performance.high efficiency,good adaptability,simple structure,changing the measuring specification in minitues(no need to change any components,just adjust ).It is an economic and practical capping equipment.
Performance advantages of this capping machine:
1. Control system---- This capping machinery adopts Mitsubishi PLC control system, random adjusting capping speed.
2. Control panel----This capping machinery is equipped with Colour touching-screen,easy-operated , stable and reliable
3.Electrical elements----This capping machinery adopts international famous brand to ensure the remarkable quality, stability and high precision.
4.Machine elements----The parts contacted with the material use the 316 high-quality stainless steel and non-poisonous, anti-corrosive PTEF hose.Other machine parts use the 304 high-class stainless steel
5 .Maintenance condition----This capping machinery fully accords to the GMP requirements, easy to disassemble and clean.
6.Changing specification----No need to change any components,easy to realize changing the cap types by simple adjusting.
7.Environmental protection configuration---This capping machinery is equipped with eco-friendly frame, realizing more clean and sanitary operation environment.(this function needs to be made to order )
Technical parameters of this capping machine:
| Capping wheel | One wheel |
| Suitable bottle diameter | 40mm - 96mm |
| Suitable cap diameter | 28mm-72mm(capping wheel is made to order) |
| Capping speed | ≤3000bottles/hour |
| Voltage | 380/220 v |
| Air source requirements | stable 0.55Mpa-0.65Mpa air |
| Overall Dimension | 1000mm×1000mm×1900mm |
| Machine weight | 200 kg |
