Help CenterCCG500-1 Semi Automatic Wine Filling Machine
Related Products
-
Two Head 1L Manual Oil Liquid Soy Liquid Shampoo Lotion Liquid Filling MachineUS$ 1 - 10,000MOQ: 1 Set -
Semi Bag in Box Filling Machine and Bottle Filling Machine ( BIB Filling and Capping Machine)US$ 1 - 4,000MOQ: 1 Set
-
24 Heads Bottle Toilet Water Filling MachineNegotiableMOQ: 1 Set
-
0.5L ~ 20L Bottle Filling MachineNegotiableMOQ: 1 Set
-
CCG1000-16B Automatic Piston Filling MachineUS$ 24,000 - 27,000MOQ: 1 Set
Specifications
Semi Wine Filling Machine1.filling kinds of wine,filling 50-500ml,filling 800b/h,1 filling head
2.SUS 304&316 ,PTEF hose, GMP
Technical performance of this piston filling machine:
Adopts special three-way filling control valve, through the cylinder repeated movement to realize filling. It is the ideal substitute equipment of manual working.
Performance advantages of this piston filling machine:
1.Control panel---- Simple interface ,pedal control switch
2.Function improvement----Feeding nozzle is equipped with blocker to prevent dropping and leaking
3.Electrical elements----Adopting international famous brand to ensure the remarkable quality, stability and high precision.
4.Machine elements----The parts contacted with the material use the 316 high-quality stainless steel and non-poisonous, anti-corrosive PTEF hose. Other main machine parts use the 304 high-class stainless steel
5.Maintenance condition----Fully accords to the GMP requirements, easy to disassemble and clean.
6.Changing specification----No need to change any components, easy to realize changing the bottle types by simple adjust.
Main Technical parameters of this piston filling machine:
| Filling head | 1 head |
| Application | 40ml-500ml(various bottle shapes) |
| Voltage | 220V/380V |
| Power | 0.1Kw |
| Filling error | ±1% |
| Filling Speed | ≤800 bottles/hour |
| Overall Dimension | 1000mm × 500mm × 1200mm |
| Machine weight: | 30 kg |
| Air source requirements | clean 0.55Mpa-0.65Mpa air |
