Help CenterCCG1000-10 Automatic Piston Injection Thick Liquid Filling Machine
Related Products
-
CCG500-8 Filling Cleaning Detergent Into Bottles (plastic and Bottle)NegotiableMOQ: 1 Set -
CCG200-6B Automatic Piston Filling MachineUS$ 13,000 - 14,000MOQ: 1 Set
-
CDP-4 Automatic Vertical Filling MachineUS$ 1 - 8,500MOQ: 1 Set
-
24 Heads Bottle Chemical Liquid Filling MachineNegotiableMOQ: 1 Set
-
5-25L Automatic Viscous Liquid Packing Machine(weight Feedback,oil,flavoring,lotion,pesticides,etc)US$ 30,000 - 35,000MOQ: 1 Set
Specifications
1.Filling thick liquid,viscous liquid,paste2.Filling type:Injection filling
3.Filling blocker:prevent leaking and dropping
Technical performance:
The filling process is under control of PLC. All operations complete on the touching screen.It adopts the piston filling way.It suits for micoviscous liquid,paste filling within chemical,daily chemical,food,cosmetic,medicine and pesticide etc.
It has properties of reliable and stable performance.high efficiency,good adaptability,can change the measuring specification in minutes(no need to change any components,just adjust ),eco-friendly outer frame,filling without dropping and leaking.It is a fairly ideal and economic filling equipment
Performance advantages:
1. Control system----Mitsubishi PLC control system, random minitrimming filling measurement
Performance advantages:
2. Control panel----Colour touching screen,easy-operated , stable and reliable
3. Function improvement----The feeding nozzle is equipped with filling blocker(prevent leaking and dropping).This machine can realize diving filling according to the material properties.(this function can be selected)
4 .Real-time alarm----Automatic alarming when the fault happens,automatic stopping and alarming when the system
appears serious breakdown.
5.Electrical elements----Adopting international famous brand to ensure the remarkable quality, stability and high precision.
6.Machine elements----The parts contacted with the material use the 316 high-quality stainless steel and non-poisonous, anti-corrosive PTEF hose.Other machine parts use the 304 high-class stainless steel.
7. Counting detection----Real- time counting,reflects the output directly.
8. Filling detection----No-bottle no-filling,it will not conduct filling if the bottles are not enough.
9.Feeding way----Bottom feeding ,without workbin.
10. Maintenance condition----Fully accords to the GMP requirements, easy to disassemble and clean.
11.Changing specification----No need to change any components,easy to realize changing the bottle types by simple adjusting.
12. Environmental protection configuration----Equipped with eco-friendly frame, realizing more clean and sanitary operation environment.
Technical parameters:
1. Filling head:16 heads (4//6/8 heads can be selected)
2. Application: 50ml-500ml(various bottle shapes)
3.Voltage: 220V/380V
4.Suitable bottle diameter: 40mm-100mm
5. Filling error: ≤±1%
6. Machine weight: 300 kg
7.Overall Dimension: 3000mm× 900mm × 2000mm
8. Air source requirements: stable 0.55Mpa-0.65Mpa air
9. Filling Speed: ≤4000bottles/hour(100ml water for test)
The production line picture
