2.5ton 2WD rough terrain forklift
| Model | RTD20 | RTD25 | |
| Power type | Diesel | Diesel | |
| Capacity | kg | 2000 | 2500 |
| Load center | mm | 600 | 600 |
| Lift height | mm | 3000 | 3000 |
| Fork size(LxWxH) | mm | 1070*120*40 | 1070*120*40 |
| Mast tilt angle(F/R) | Deg | 10°/12° | 10°/12° |
| Length to face of fork | mm | 3060 | 3060 |
| Overall width | mm | 1604 | 1604 |
| Mast lowered height | mm | 2115 | 2115 |
| Mast extended height | mm | 4250 | 4250 |
| Overhead guard height | mm | 2200 | 2200 |
| Turning radius | mm | 2750 | 2750 |
| Min. right angle aisle width | mm | 2615 | 2615 |
| Front overhang | mm | 601 | 601 |
| Ground clearance | mm | 265/250 | 265/250 |
| Wheelbase | mm | 1835 | 1835 |
| Travel (no load) | km/h | 22/22 | 22/22 |
| Lifting (full load) | mm/s | 480/550 | 480/550 |
| Gradeability(laden) | % | 20 | 20 |
| Service weight | kg | 3590 | 3790 |
| Front tire | 14-17.5-14PR | 14-17.5-14PR | |
| Rear tire | 27X10-12-12PR | 27X10-12-12PR | |
| Battery (voltage/capacity) | v/ah | 12/90 | 12/90 |
| Engine model | 4TNE98-BQFLC | 4TNE98-BQFLC | |
| Engine rated output/r.p.m | kw | 42.1/2300 | 42.1/2300 |
| Engine rated torque/r.p.m. | n.m | 186-206/1700 | 186-206/1700 |
| Engine No.of Cylinder | 4 | 4 | |
| Bore x stroke | mm | 98X110 | 98X110 |
| Tranmission Model | Automatic | Automatic | |
| Drive type | 2WD | 2WD |
1- Rough terrain forklift, wide view forklift mast, it is suitable for hard and rugged terrain working condition.
2- It is tires are big patterm, wideth tires, It is specialized designed for hard , terrain road and way.
3- Working condition of cross-country road is rugged, obstacles in the way. The ground clearance of normal forklift is too low, However, the rough terrain forklift designed rear ground clearance of 265 mm, improved its aim to best working for rough.
4-The driving axle is conbined in Cast steel structure, it get more stength and reliable.
5-You can optional Chinese engine, Japanese engine, which are prefer to you.
Nude in container or sea worthy package
If anything go wrong within12months or 1000 hours, which ever come first from the date of purchase Goodsense will pay for parts to have the repairs conducted any shipping expenses will be also paid by Goodsense and in return,clents need to give back the parts needed to be exchanged to Goodsense, with shipping expenses paid. If a part is bad and urgent, clients take photos of scutcheon, side of the whole forklift and the bad part, Goodsense can send out the part within a day, and if the weight not excess 10KGs, Goodsense can deliver parts toclients by DHL,Fedex or else, if it is heavier, shipped by sea within a day. as for the labor, Goodsense will refund clients with 100dollar per set,if clients order quantity excess 20 sets yearly.
Goodsence will not be responsible for damage cause by the user or owner or lack of required maintenance or abuse.
1.What's the Certificate do you have?
Goodsense workshop meet with the ISO9001 Quality System. And all of our products are with CE certificate. Epa approval can be available if needed.
2. Can you customize and design as the clients' requirement?
Goodsense will try its best to meet all kinds of clients' special requirements. And for new products that have not been into the market yet, we have our technical team to help the clients. All kinds of attachments such as roll paper clamp, side shifter and so on can be available.
3. How long is the warranty of your products?
All of products are with 1 year / 1000 working hours subject to the first.
4. Can you produce the products labeled with the client's brand?
Yes, we do!
With the authorization of the brand, we can OEM for our clients.
5. What's the payment terms do you accept?
Normally we accept 30% deposit, 70%balance before delivery.
6. Delivery date:
If clients need normal products, we will deliver the products within 25days. If clients need customerized products, the delivery date depend on the requirements.
