Help CenterHigh Voltage Epoxy Resin 12kv CG2 Capacitive Insulator
Related Products
-
Epoxy Resin CG2 Capacitive InsulatorUS$ 3 - 15MOQ: 10 Pieces -
High Quality Epoxy Resin 130mm Height CG3 Capacitive InsulatorUS$ 3 - 15MOQ: 10 Pieces
-
Manufacturer Epoxy Resin 24kv CG3 Capacitive InsulatorUS$ 3 - 30MOQ: 10 Pieces
-
China Manufacturer Supply 24kv Epoxy Capacitive InsulatorUS$ 3 - 35MOQ: 10 Pieces
-
China Supply Epoxy Resin Capacitive Divider InsulatorUS$ 3 - 30MOQ: 10 Pieces
| Type: | CG2 Capacitive Insulator |
| Rate voltage: | 12kv |
| Creepage distance: | > 240mm |
| Power frequency withstand voltage: | 42 kv/min |
| Partial discharge: | <10 PC |
| lighting impulse withstand voltage: | 75kv |
| Bending strength: | >10kN |
| Capacitance= | 120 PF |
1. Adopts epoxy resin automatic pressure gel craft that be APG craft manufacture, Product beautiful, Machine, Electrical performance fit.
2. Adopts high toughness epoxy resin manufacture, Machine capability excellent. And adopts low reaction activity recipe system, Material solidifies slow, Product body stress low reaction activity recipe system, Material solidifies slow, Product body stress low, Maximum field enhances product's machine capability.
3. Adds activated silica slight powder, Furthurs enhance epoxy resin's machine capability, Much ensures insulate long-term keep good electric insulate performance under wet work environment.
4. Adds organic color, Product color and lustre bright, Does not reduce product's insulate performance.
Company profile:
EUNOV(XIAMEN) ELECTRICAL ENGINEERING CO.,LTD.is a joint-venture company located at Xiamen Hi-tec. I.D.Z., P.R. of China since 2003. We are a leader in the design and manufacture of epoxy components for the electrical power equipment industry. We do business with the philosophy that our most important product is customer satisfaction. We are now the supplier of Italian VEI(Xiamen), AREVA(Xiamen),etc.
Specializing in manufacture of epoxy resin insulators, we have lots of kinds of insulators from 145kV to 7.2kV, such as Spouts, Bushings, Post insulators, Capacitive insulators, Voltage indictors, and such special advanced components as applied on C-GIS, SIS, EMBEDDED POLES, SF6 airproof system, etc., featured as compact design, high reliability, electric field equilibrium, for outdoor and indoor application. We has built up extensive expertise in material control, casting technology , testing ways and application data in APG ( Automatic Pressure Gelation ) field. Also we welcome the OEM business, and would like to tailor your special need all through mould design to casting.
