Specifications
The high frequency plastic welding machine:Imported Toshiba oscillating tube, with stable, reliable output
Double-head High Frequency Plastic Welding Machine
(NK-GJ0043)
Double-Head High Frequency Plastic Welding Machine-Technical Data:
Model: NK-GJ0043
HF Output: 4KW/5KW/8KW
Vibration frequency: 27.12mMHZSupply
voltage: AC380V
Max input power: 6KVA/8KVA/12KVA
Oscillating: E3062/7T85RB/7T69RB
Rectifying tube: HVP-14
Maximum pressure: 90kg/90kg/1.5T
Lower pole plate: 350*700/350*700/450*800mm
Travel distance: 60/60/70mm
Mode of pressurization: Foot operated
Double-head High Frequency Plastic Welding Machines-configuration:
1.Imported oscillating tube, with stable, reliable output
2.High-sensitivity spark arrester, protecting molds effectively
3.Overload protector
4.Key electric assemblies assembled from imported high-quality parts
Double-head High Frequency Plastic Welding Machines--Functional description:
1. High-sensitivity spark protection: This unit is equipped with a special electronic circuit that cuts off high frequencies to arrest sparks, minimizing the damage to the electrode and material, while the warning lamp gives an alarm.
2. Wave interference protector: A frequency stabilizer and a high-frequency magnetic leakage arrester are provided to prevent wave leakage from interfering with other electronic devices.
3. Overload protector: Avoiding frequency drift as a result of improper operation
4. Strong head: Strong enough for any situation, handy and precise to use5.Adjustable tuner: Output power can be adjusted at the tuner according to electrode size and material thickness. Required welding time has been cut down greatly to raise the machine's productivity.This unit applies to the fusion and embossing of inflatable toys, slippers, handbags, purses, belts, bags, stationery, stickers, trademarks, PVC tapes, etc.
Update Date:2011-07-28 5:10:13
