Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > EXFO FTB-1 Handheld SM OTDR W/ FTB-730 Module and FIP 400 Probe
EXFO FTB-1 Handheld SM OTDR W/ FTB-730 Module and FIP 400 Probe
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Canada
Brand Name:
EXFO
Model Number:
FTB-1-730
Payment & Shipping
Payment Methods:
Port of Shipment:
HongKong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
EXFO FLS-300 Optical Light SourceUS$ 1,150 - 1,250MOQ: 1 Unit -
EXFO FPM-300 Power MeterUS$ 400 - 480MOQ: 1 Set
-
Exfo PPM-350C PON Power Meter PON Power Meter, 2 Ports, Extended Range, BPON, EPON, GPON | FTTXNegotiableMOQ: 1 Set
-
OTDR FTB-1 WITH FTB-720 SM OTDR OR MM/SM OTDR PRICEUS$ 4,200 - 6,000MOQ: 1 Set
-
OTDR EXFO AXS-110 / AXS-100 OTDR Handheld OTDR IN STOCKUS$ 1 - 5,300MOQ: 1 Set
Place of Origin
Canada
Brand Name
EXFO
Model Number
FTB-1-730
EXFO FTB-1 Handheld SM OTDR W/ FTB-730 Module and FIP 400 Probe
Contact information
Mobile: 0086-13823128817
Tel:+86-755-36934393
Fax: 0086-755-33503470
Website: www..hk
Skype: kitty.hsv
Skype:kitty.hsv
FTB-730 and FTB-7300E— PON FTTx/MDU OTDRs
PLATFORM COMPATIBILITY For FTB-7300E
FTB-500 Four- or eight-slot platform for fiber characterization
FTB-200 Two-slot modular platform for combined applications
OPTIMIZED FOR ACCESS FIBER DEPLOYMENTS AND TROUBLESHOOTING
KEY FEATURES
Test through high-port-count splitters (up to 1x128)
Singlemode port for in-service troubleshooting
Dynamic range of up to 39 dB
Short acquisition time to speed up deployment process
| Kit Models | Description |
| TK-1 | TK-1-700 Kit - FTB-1 Base Mainframe Single-slot capacity Modular mainframe - Touchscreen, color, 800 x 480 TFT, 178 mm (7 in) - Storage: > 16 GB Internal Memory - Interfaces > RJ-45 LAN 10/100/1000 Mbit/s > USB 2.0 ports (qty:2) > Fiber inspection probe connector port (video) |
| FTB-730-000-04B-XX | SM OTDR Module Filtered 1625 nm, 39 dB (9/125 µm) for live fiber testing with in-line power meter (one broadband channel) |
| FTB-730-000-08B-XX | SM OTDR Module Filtered 1650 nm, 37 dB (9/125 µm) for live fiber testing with in-line power meter (one broadband channel) |
| FTB-730-023B-04B-XX | SM OTDR Module Port 1: 1310/1550 nm, 39/37 dB (9/125 µm) Port 2: Filtered 1625 nm, 39 dB (9/125 µm) for live fiber testing with in-line power meter (one broadband channel) |
| FTB-730-023B-08B-XX | SM OTDR Module Port 1: 1310/1550 nm, 39/37 dB (9/125 µm) Port 2: Filtered 1650 nm, 37 dB (9/125 µm) for live fiber testing with in-line power meter (one broadband channel) |
| FTB-730-023B-XX | SM OTDR Module 1310/1550 nm, 39/37 dB (9/125 µm) |
| FTB-730-034B-XX | SM OTDR Module 1550/1625 nm, 37/37 dB (9/125 µm) |
| FTB-730-234B-XX | SM OTDR Module 1310/1550/1625 nm, 39/37/37 dB (9/125 µm) |
| FTB-730-236B-XX | SM OTDR Module 1310/1490/1550 nm, 39/38/37 dB (9/125 µm) |
