Specifications
1.Customized hammer crusher2.power:11kw
3.Simple operation and structure
4.Long operating life
Introduction of hammer crusher:
Hammer crusher is widely used in metallurgy, mining, chemical, cement, coal gangue, construction, sand, refractory material, ceramic and other industrial and mining enterprises, engaged in breaking and crushing the material in the operation. It is mainly suitable for crushing various soft and hard ore. whose compression strength is not higher than 320MPa (MPa),such as coal, salt, chalk, gypsum, blocks, limestone, etc.
The main working part of hammer crusher is rotors with hammer. The rotors consist of main shaft, disk, pin shaft and hammers. The motor drives the rotors to rotate quickly in the crushing cavity. Raw materials enter the crusher through the feed opening and are stricken, impacted, cut and ground by the high-speed hammer to small size.
Applications of hammer crusher:
Hammer crusher is widely used in processing plants, refractory plants, cement, glass and other industrial sectors with medium hardness materials are finely ground. Can be used for dry or wet crushing, the material should be seeped before crushing , seepage is not allowed for dry crushing.
Working principle of hammer crusher:
The motor drives the rotor rotates at high speed in the crushing cavity. Material from the upper opening to feed into the machine, under hitting, impacting, shearing, abrasive and high-speed movement of the hammer and can be smashed. the crushed material smaller than the mesh size of the sieve which in the lower part of the rotor discharged , the larger one retained on the sieve and grinding continued to be hit by the hammer, and finally output through the sieve.
Parameters of hammer crusher:
| Specifications | Feeding size(mm) | Discharging size(mm) | Capacity(m³/h) | Motor power(kw) | Dimensions(L*W*H)(mm) |
| PCØ400*300 | ≤200 | ≤25 | 5-10 | 11 | 900*670*860 |
| PCØ600*400 | ≤250 | ≤30 | 10-22 | 22 | 1200*1050*1200 |
| PCØ800*600 | ≤250 | ≤35 | 18-40 | 55 | 1310*1180*1310 |
| PCØ1000*800 | ≤350 | ≤35 | 25-50 | 75 | 1600*1390*1575 |
| PCØ1000*1000 | ≤350 | ≤35 | 30-55 | 91 | 1800*1590*1775 |
| PCØ1250*1250 | ≤350 | ≤35 | 35-65 | 132 | 2060*1600*1890 |
| PCØ1400*1400 | ≤350 | ≤35 | 50-100 | 280 | 2365*1870*2220 |
| PCØ1600*1600 | ≤350 | ≤35 | 100-150 | 480 | 3050*2850*2800 |
Pictures of hammer crusher:
Hammer crusher manufacting process:
Payment Terms of hammer crusher:
- Payment methods are T/T, L/C,D/A,D/P;
- We take pictures of finished hammer crusher before delivery.
Packaging of hammer crusher:
- Sand blasting, coat with high quality paint;
- Product wrap by PP-Bubble;
- Load container, Spear Parts in wooden case.
Our service of hammer crusher:
- Installation and adjustment of hammer crusher: The Installation and adjustment of our hammer crusher is provided by our company. Technicist of hammer crusher will provided by supplier for buyer to assist the work such as weding connecion of shell body ,equipment installation, adjustment, training etc.
- Quality of guarantee of hammer crusher : Three-guarantees of hammer crusher and warrantly period id one year.
- Technical support of hammer crusher is provided from the beginning to the end.
- Luoyang Zhongde Heavy Industries Co., Ltd, whose predecessor was Luoyang Mining Machinery Cement Equipment Factory, was founded in 1959.
- Over the past fifty years, it has made significant contribution to the economic development in China.
- In 1995, it took the lead in changing into the joint stock company, which brought rapid development to the company .
- In 2006, the old factory relocated into the large modern industrial workshop in Luoxin Industrial Park.
How about the quality of your hammer crusher?
- Our hammer crusher is manufactured strictly according national and international standard.
- We take a test on every hammer crusher before delivery.
How about price of your hammer crusher?
- We can give the lowest price of hammer crusher than market one.
- We do quotation of hammer crusher as soon as possible for any custome.
- Discount of hammer crusher can be given according to quantity.
How about the after-sale service of your company?
- Our engineer is aviliable to installation hammer crusher overseas.
- The guarantee period of our hammer crusher is one year.
