Reliable Quality Powerful Diesel Genset

Reliable Quality Powerful Diesel Genset thumbnail-1
Reliable Quality Powerful Diesel Genset photo-1
US$ 450 - 5,565 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangxi, China
Brand Name:
LD
Model Number:
80GF
Contact Supplier Request Quote Chat Now
Liuzhou Long Dao Industrial And Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or Guangzhou Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangxi, China
Brand Name LD
Model Number 80GF
Output Type AC Three Phase
Speed 1500 or 1800 r/min, 1500rpm and 1800rpm
Frequency 50 or 60 HZ
Rated Power 80KW/100KVA
Rated Voltage 230/400 V
Rated Current 144 A

Specifications

diesel genset
1.Yuchai and FEV Germany technology
2.Price less 20%-30% than other brand
3.CE & ISO9001:2008

Main Product: diesel engine, diesel generator, alternator and spare parts;

Diesel Engine Usage: Widely used for generator set, boat, wheel loader, truck, water pump, sand pump,

                                     fire pump, construction machine, etc;

Diesel Engine Power Range: from 20kw up to 700kw;

Diesel Generator Power Range: from 30kw up to 700kw.



Reliable Quality Powerful Diesel Genset Technical Parameters
Model  80GF
Rated Power  80KW/100KVA
Rated Voltage(v)  400/230
Rated Current(A)  144
Rated Frequency(HZ)  50 or 60
Rated Speed (r/min)  1500 or 1800
Regulator Approach  AVR
Phase  Three-phase Four-wire
Start Type  Electric
Net Weight(Kg)  1250
Dimension(mm)  2600×800×1300
Diesel Engine LD Brand 6B135Z
Output Power(KW) 99KW
Fuel Consuption (g/kw.h) ≤205
Start Type Electric
Alternator SIEMENS & Standford
 1FC6 282-4
Controller Smartgen 6120

Reliable quality powerful diesel genset

Powerful Diesel Genset Power Range for Option.

Genset 400/230V 50HZ 3-PHASE Model
Prime Power Engine Alternator Controller
Type KW KVA LD Brand WATTEK (Stanford Technology) SMARTGEN
30GF 30 37.5 4F50  184H 6120
40GF 40 50 4F65Z  224D 6120
50GF 50 62.5 4D85Z  224E 6120
60GF 60 75 4D110L 224F 6120
80GF 80 100 6B135Z  274C 6120
100GF 100 125 6B170L  274D 6120
120GF 120 150 6B210L 274E 6120
150GF 150 188 6LA245L  274G 6120
160GF 160 200 6LA265L  274H 6120
180GF 180 225 6LA285L  274J 6120
200GF 200 250 6LM350L  274K 6120
250GF 250 312.5 6M420L    444D 6120
300GF 300 375 6MK510L  444FS 6120
360GF 360 450 6MJ570L 544 6120
400GF 400 500 12M690L 544C 6120
468GF 468 585 12M750L 544E 6120
500GF 500 625 12MJ840L 544FS 6120
600GF 600 750 12MJ1050L  634B 6120
640GF 640 800 12MJ1050L  634C 6120

Reliable quality powerful diesel gensetReliable quality powerful diesel genset

Powerful Diesel Genset , 6B135Z Engine, Stamford Technology

Alternator and Smartgen Controller 6120

LD 80kw silent diesel generator, is equipped with LD 6B135Z engine, which is 6 cylinders, 4 stroke,

80kw power. The engine with the characteristics of powerful, stability, less fuel consumption, long

operation hours and life, and lower noise. Engine speed is  1500 and 1800 rpm for option.



The Wattek alternator, which produced by Stamdford technology. With the same look and shape as origin

Stamdford alternator, wattek alternator have been very popular in current market due to its high quality.



And the Smartgen 6120 controller, which is the best controller made in China, is widely used in chinese

Genset manufacturer.

Powerful Diesel Genset Technical Warranty Service

1.Warranty iterms will be issued by our own factory, which is simple and quick;

2.Warranty period will be 12 monthes or 1500 working hours from commissioning date;

3.Parts replacement under warranty will be sent (include sea freight and insurance) to buyers;

4.Easy torn prts are excluded in the warranty, like plugs, condenser, fuse, battery, seal;

5.Problems caused by customer's incorrect man-made operation will be covered by the user;

6.Part use for overhual and ordinary maintanence will be offered by us in factory price;

7.Skillful engineers of us are available dispatched to customers place for training and service.

Powerful Diesel Genset Technical CE Certificate

Reliable quality powerful diesel genset

Reliable quality powerful diesel genset
