LD6LM390L 260KW China Engines China Diesel Engine Trader

LD6LM390L 260KW China Engines China Diesel Engine Trader thumbnail-1
LD6LM390L 260KW China Engines China Diesel Engine Trader photo-1
US$ 9,140 - 9,250 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other, Generator
Fuel:
Diesel
Contact Supplier Request Quote Chat Now
Liuzhou Long Dao Industrial And Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Usage Other, Generator
Fuel Diesel
Stroke 4 Stroke
Cylinder Other, 6 Cylinder
Cold Style Other, Water-cooled
Start Electric Start
Place of Origin Guangxi, China
Brand Name LD Brand
Model Number LD6LM390L
Dimension(L*W*H) 1380x820x1150 mm
Weight 800 kg
Certification ISO9001:2008, CE
Warranty 12 Month
After-sales Service Provided Overseas third-party support available

Specifications

1. Germeny FEV, Yuchai Technology
2. ISO9001, CE Certificates Approved
3. Sharing Yuchai Origin Diesel Engine Parts

LD6LM390L 260KW China Engines China Diesel Engine Trader

       LD Brand engines are manufactured by our own factory Liuzhou HD Power Machinery and Manufacturing

Co,.Ltd, which we have been in this engine poduction field more than 10 years. There, all our LD Engines are

4 Stroke, water cooled, and strict according with ISO9001 system standard.

LD6LM390L 260KW China Engines China Diesel Engine Trader

      LD6LM 6 cylinder 4 stroke series engines are one our our main engines series, that with technology from

Germany, FEV and Yuchai companies. 6LM series has four sisters engines: 6LM350L, 6LA390L,which the

speed can be 1500rpm and 1800rmp; all engines will equip with turbocharger and inter cooler!

 LD6LM390L 260KW China Engines China Diesel Engine Trader



l   Advanced Technology & Design Origin from Germany FEV, Yuchai companies, with more compact structures,

      engine overhaul can met more than 12000 hours;

l   Common Parts Supply System Parts will share Yuchai engines parts supply system, cheap and easy to get;

l   Environmentally Operation Fuel consumption will lower 205g/kw.h, with lesser vibration, noise;

l   Application Diesel genset power range from 210kw to 230kw.

Model

LD6LM350L

LD6LM390L

Type

Vertical, in-line, water-cooled, 4-stroke

Intake Way

Turbocharged Inter-cooled

No Cylinders, Bore x Stroke(mm)

6-113x155

Displacement(L)

9.3

Compression ratio

17.5:1

Rated power/speed(kW/r/min)

235/1500

235/1800

260/1500

260/1800

Standby power/speed(kW/r/min)

258/1500

258/1800

268/1500

268/1800

Min fuel consumption g/(kW·h)

≤195

Oil capability(L)

20~22

Oil Consumption g/(kW·h)

≤1.0

Starting Type

Electric Sart

Noise limit dB(A)

≤102

Regulator Approach

Electric

Governing Rate

≤1%

Flywheel house/flywheel

1#14

Suitable height above sea level

≤2500

Dimmension(mm)

1380x820x1150

Net weight(kg)

800




LD6LM China Engines China Diesel Engine Trader Technology

1.OEM engine manufacturer in China, Diesel Engine Seller and Chinese Diesel Engine;

2.Technology origin from Germany, FEV, Yuchai companies;

3.With certificates ISO9001:2008, CE:2006/42/EC certificates approved;

4.Share parts supply system with origin Yuchai engines;

5.D&R (Develop and Research) team/experts have more than 15 experience in this field;

6.Engine assembly solution and CKD service is available to offer to customers;

 LD6LM390L 260KW China Engines China Diesel Engine Trader





LD6LM China Engines China Diesel Engine Trader Warranty

1.Warranty iterms will be issued by our own factory, which is simple and quick;

2.Warranty period will be 12 monthes or 1500 working hours from commissioning date;

3.Parts replacement under warranty will be sent (include sea freight and insurance) to buyers without charges;

4.Easy torn prts are excluded in the warranty, like plugs, condenser, fuse, battery, seal;

5.Problems caused by customer's incorrect man-made operation will be covered by the user;

6.Part use for overhual and ordinary maintanence will be offered by us in factory price;

7.Skillful engineers of us are available dispatched to customers place for training and service;





Mr.Guangbin Liang(Tony)

(Export/Sales Manager)

Tel: +86 18978043291       Fax: +86 (0)772 2875155

Email: guangbinliang(at)

Skype: guangbin.liang            QQ:491383357

LD6LM390L 260KW China Engines China Diesel Engine Trader
