XK-SX1A Electrical Trainer Primary and Intermediate Maintenance Electrician Training and Evaluation Device ISO Cetifications
1. Product overview:
XK-SX1A type primary electrician training evaluation deice use electrical control cabinet as main cabinet, using double side of cabinet, arrange electrical appliance and assorting experimental component, can complete electronic traction control and light circuit practical training project in primary electrician evaluation. Reasonable design, easy to practice, took less square. To length electrical appliance using life, each electrical appliance contact connect with wiring terminal, let student wires at wiring terminal, connect motor, electrical appliance to complete various control experiment, to reduce material consume, extension using life. With over voltage, over current, over load, leakage protection, to guarantee experiment process safety
2. Product main technical indicator
2.1 Size: 800mm*540mm*1700mm;
2.2 Power supply source: the three-phase AC380V, power < 2000 VA
2.3 Three phase power main switch with leakage protection IΔn< 30mA,time < 0.1S
2.4 With accident sudden stop button, power source indicator, power supply indicator
3. Device accessories
3.1 Experiment guide wires 20pcs
3.2 Three phase asynchronous motor 1pcs
4. Experiment list
4.1 Three-phase motor control
1)Direct starting asynchronous motor circuit
2)Asynchronous motor point start control circuit
3)Asynchronous motor self-locking control circuit
4)The two asynchronous motor (more) control circuit
5)Y-train start automatic control circuit
6)With the fall of switch of the three-phase asynchronous motor control and reversing
7)Asynchronous motor contactor interlocking positive &negative control circuit
8)Asynchronous motor button interlocking positive &negative control circuit
9)Automatic sequence starting control
10)Manual starting control order
11)Asynchronous motor energy consumption control circuit
12)Single button control motor power outage on the way
13)Asynchronous motor reverse connect braking control circuit
14)Asynchronous motor double interlocking positive &negative control circuit
15)Positive &negative point move, starting control circuit
16)With a point of automatic control circuit and move
17)Position switch as the automatic stop and reversing start control circuit
18)The string of resistance step-down start control circuit
19)Single motor starting control circuit
20)C620-type 1 lathe control circuit
21)The electric hoist electric control circuit
4.2 Instrument and lighting experiment, practice project
Incandescent lamp control circuit
Fluorescent lamp control circuit
Touch switch control incandescent lamp circuit
Voice control switch control stair incandescent lamp circuit
Infrared switch control stair incandescent lamp circuit
Single phase watt-hour meter installed directly circuit
Single phase watt-hour meter indirect installation circuit
Three-phase watt-hour meter installed directly circuit
Three-phase watt-hour meter indirect installation circuit
Voltmeter and ammeter installation circuit
Current transformer and ammeter with connection circuit
A current transformer used in single-phase circuit connection circuit
Three table current transformer joint into star line connection circuit
Three table current transformer joint into triangle connection circuit
Two sets of current transformer differential connection circuit
Universal switch and voltmeter measurement three-phase voltage wiring circuit
