XK-SX2C Senior Maintenance Electrician Training Device,Electrical Equipment for Teaching Aids
1. Product overview:
XK-SX2C Senior Maintenance Electrician Training Device,Electrical Equipment for Teaching Aids is used for training for PLC programmable controller, inverter speed regulator, electrician maintenance training module training, can fast master course required practical technology and operating skills.
Training set adopts bench structure, with wheels, freely to move, table is made of fireproofing, waterproofing, high wear resistance plate.
2. Experimental bench technical parameter
2.1 Size: 1600mm*730mm*1500mm
2.2 Power supply source: the three-phase AC380V, power < 1500 VA
2.3 Three phase power supply main switch with leakage protection IΔn≤30mA, time≤0.1S
2.4 With accident sudden stop button, power source indicator, power supply indicator
3. Experimental bench accessories
3.1 Experiment guide wire 20pcs
3.2 Three phase asynchronous motor 1pce
3.3 Dual speed motor 1pce
3.4 DC motor 1pce
3.5 Experiment manual 1 book
4. Experiment list
4.1 Electrician training project
1) Three phase asynchronous motor direct start control
2) Three phase asynchronous motor contactor inching control circuit
3) Three phase asynchronous contactor self lock control circuit
4) Three phase asynchronous motor contactor inching and self lock control circuit
5) Three phase asynchronous motor button interlock front and reverse turn control circuit
6) Three phase asynchronous motor contactor interlocking front and reverse turn control circuit
7) Three phase asynchronous motor button contactor duplex mechanical interlocking
8) Three phase asynchronous motor manual sequence control
9) Three phase asynchronous motor automatic sequence control
10) Three phase asynchronous motor multiple places control
11) Three phase asynchronous motor serial resistance decompression start manual control circuit
12) Three phase asynchronous motor stator serial resistance reduced voltage start control circuit
13) Three phase asynchronous motor energy consumption control circuit
14) Three phase asynchronous motor reverse connect braking control circuit
15) Three phase asynchronous motor star-delta start manual control circuit
16) Three phase asynchronous motor star-delta start automatic control circuit
17) Working platform automatic reverse control circuit
18) Position switch as automatic stop front back reverse inching control circuit;
19) Automatic round tripping control circuit;
20) Contactor control double speed motor control circuit
21) Time relay control double speed motor control circuit
22) Shunt excited DC motor as stator current law add excited inching control circuit
23) Shunt exited DC motor armature circuit serial resistance inching and speed adjustment
24) Shunt exited DC motor with dynamic braking reverse turn control circuit
25) Shunt exited DC motor excitation reverse connect braking control circuit
4.2 PLC training project
1)PLC basic commands programming exercises
2)LED digital display and control
3)The light of tower simulation control
4)Assembly line control simulation
5)The material of car control experiment
6)Four ways of the simulation of the contest
7)Automatic ingredients/three conveyor belts
8)Electroplating production line of simulation control
9)The mill simulation control
10)Robots experiment
11)Control forming machines simulation
