Brief Introduction
R-902-1 low-resistivity insulating enamel is a two-component enamel which made from acrylic resin, polyurethane curing agent, conductive filler, auxiliaries and thinner. It dries in room temperature.
Features
Fast dry, wear resistant, excellent gloss and color retention, good conduction and insulation performance, good oil and arc resistance.
Application/Use
Very suitable for coating of parts need electric conduction.
Qualification (as the Q/R 101-2010 company standard)
No. |
Test Item |
Unit |
Value |
|
1 |
Appearance, test Tube |
- |
Smooth film, color accords with the standard template |
|
2 |
Viscosity, 4#cup, 23±1°C |
s |
50-100 |
|
3 |
Fineness, scraper fineness test |
um |
≤25 |
|
4 |
Drying time |
Dry to touch |
h |
≤0.5 |
Hard dry |
≤24 |
|||
5 |
Gloss - |
% |
≥90 |
|
6 |
Hardness, pendulum method |
- |
≥0.5 |
|
7 |
Impact strength |
kg·cm |
50 |
|
8 |
Adhesion, circle method |
level |
1 |
|
9 |
Resistance value |
MΩ |
≤35 |
|
How to use
- Mix component A and component B as proportion and to use it right after it was ready. Should you wish to reduce its viscosity, our R-902-X should be used.
- The unit should be dry, clean, no greasy dirt and dust. Brushing, spraying and dipping will be suitable.
- Drying condition: Place the unit in room temperature for 24h until turns dry. As our test, the unit would dry in 1h at 50-100°C.
Established in 1992, Rota Group is one of the most professional manufacturers of impregnating varnish, mica tape, potting resin and embedding resin in China. Most products have been approved by ISO9001, 14000, UL, TUV, FDA, RoHS and REACH, widely used in high-voltage motors, wires and cables, household appliances, industrial pumps, and metallurgy equipments etc. We win the trust of the majority of well-known manufactures, like BOSCH, BLACK & DECKER, Fujitsu, Shibaura, REGAL, Siemens, EPCOS, N.P.V. and so on.
Professional quality, creating value for customers. Rota Group lead in the aspects of industry scale, product technology and innovation capacity, we will provide quality products and professional services for you. Welcome you!
