Home > Chemicals > Paint & Coating > Building Coating > Trickle Resin of Epoxy R-1146, Insulating Varnish,

Trickle Resin of Epoxy R-1146, Insulating Varnish,

Name: Trickle Resin of Epoxy R-1146, Insulating Varnish,
Brand: Rota
SKU: 109944983

Trickle Resin of Epoxy R-1146, Insulating Varnish, thumbnail-1

Trickle Resin of Epoxy R-1146, Insulating Varnish, thumbnail-2

Trickle Resin of Epoxy R-1146, Insulating Varnish, photo-1

Trickle Resin of Epoxy R-1146, Insulating Varnish, photo-2

US$ 3.82 - 3.82 MOQ: 500 Kilograms

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Main Raw Material:

Epoxy

Usage:

Electrical Insulating Varnish

Contact Supplier Request Quote Chat Now

Jiaxing Rota-Ropa Insulating Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Main Raw Material Epoxy

Usage Electrical Insulating Varnish

Application Method Other, trickle impregnating

State Liquid Coating

Brand Name Rota

Model Number R-1146

R-1146 Epoxy Trickle Resin

Introduction

R-1146 epoxy trickle resin is made from epoxy resin and hardener presented in two-component form, with thermal class F. It has gained UL certification (No.: E227128) and UL insulation system certification (No.: E242776), and comply with the RoHS environmental requirements.

Features

Excellent thermal state mechanical strength and electrical performance, good heat resistance and mould proof, fast curing, firm and thick condensate, superior quality.

Applications

It is widely used and suitable for trickling of high temperature, high rotation speed, minitype or small type rotor coil, such as: electrical tool, cleaner and auto motors.

Qualification (as the Q/R 101-2010 company standard)

Test Item		Test Method	Unit	Value
Component A	Appearance	Test Tube	-	Buff transparent liquid
Component A	Viscosity	23±1°C	mPa.s	11000~15000
Component B	Appearance	Test Tube	-	Buff to Reddish brown transparent
Component B	Viscosity	Tu-4# cup, 23±1°C	s	≤60
Mixture (A:B=5:4)	Gel time	130±2°C	min	4-7
	Viscosity	25°C after 15h	mPa.s	≤8000
	Volatile content	130±2°C ,1h	%	≤1.0
Condensate	Dielectric Strength	Normalcy	MV/m	≥20
	Dielectric dissipation factor	Normalcy	%	≤1
	Volume Resistivity	Normalcy	Ω·m	≥1×10¹³
	Volume Resistivity	155±2°C	Ω·m	≥1×10⁷
	Curing in thick layer	1h/130±2°C	-	No worse than S1U1I3,2,
	Pot life	-	h	≥8

Established in 1992, Rota Group is one of the most professional manufacturers of impregnating varnish, mica tape, potting resin and embedding resin in China. Most products have been approved by ISO9001, 14000, UL, TUV, FDA, RoHS and REACH, widely used in high-voltage motors, wires and cables, household appliances, industrial pumps, and metallurgy equipments etc. We win the trust of the majority of well-known manufactures, like BOSCH, BLACK & DECKER, Fujitsu, Shibaura, REGAL, Siemens, EPCOS, N.P.V. and so on.

Professional quality, creating value for customers. Rota Group lead in the aspects of industry scale, product technology and innovation capacity, we will provide quality products and professional services for you. Welcome you!
