Specifications
Coil Plate or Metal Sheet Leveling Machine/Straightening Machine1.Thickness of sheet plate:0.25-2 mm
2.Width:500-1300mm
Dear Customers,
This is Ada,thanks for your interest in our products. The following is for your reference, we have our own design teams and factory ,we can design according to your requirement.Welcome your inquiry,I will reply you as soon as possible.
A.Specification:Coil Plate or Metal Sheet Leveling Machine/Straightening Machine
1.Thickness of sheet plate:0.25-2 mm
2.Width of coiled plate:500-1300mm
3.Precision of leveling:0.2mm/2000mm
4.Weight of machine :10T
5.Application :carbon steel plate, galvanized sheet, color plate, stainless steel,
hot rolled ,cold rolled etc
6. b≤450Mpa;S ≤260Mpa
B.Features of Machine
To graduate from professional uneven plates in the leveling and guide steel belt into the right place after working procedure.
Support rollers function : Make leveling roll force equilibrium, and can be reduced to the wear and tear from the roller .
Roller processing flow :Raw materials-conditioning quality-rough machining-hardening -precision machined
Power part: This is composed of power stand, decelerator, direct-current speed adjustable motor: 45KW, electric cabinet, motor wheel, coupler, power distributing case, universal cross joint, 19+2 groups of spindle and connect cover, etc.
Host machine: This is composed of bottom-stand, frame, under-axle stand, sliding axle stand, 19pcs of leveling roller(roller diameterφ150mm),upper pressing frame, up and down supporting wheel stand, supporting wheel, mechanically lifting &
pressing device, accompany of two motors: 2.2KW
If you intend to buy a straightening for the coil plat or metal sheet , just tell me the parameter as above,we can produce the straightening machine according to your requirement !
If you need more information,please feel free to contact me.I will do my best to help you.
Best wishes
Skype:adawei1019
Moibile:0086-13662169442
Hengxing Metallurgical Machinery Manufacturing CO.,LTD. has a history of more than 14 years in the steel equipment manufacturing industry,with an annual production of 60 sets of various types of equipment,400 tons of roll,the annual sales is RMB80,000,000. Our products are being sold to many countries ,such as Brazil in south america,Ukraine in eastern Europe,Kazakhstan,Kenya,India and some other countries.We have won overseas customer's trust.
