Z60 0.65~0.70*1000mm Galvanized Steel Sheet

US$ 695 - 720 MOQ: 20 Tons

Key Specifications

Standard:

AISI, ASTM, BS, DIN, GB, JIS, Other, AISI, ASTM, BS, DIN, GB, JIS, EN

Grade:

DX51D / DX52D/ DX53D/ S250,280,320GD

Thickness:

0.65~0.70mm

Donge Yike Panel Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QingdaoTianjin China

Delivery Detail:

Delivery time depends on order quantity.

Standard AISI, ASTM, BS, DIN, GB, JIS, Other, AISI, ASTM, BS, DIN, GB, JIS, EN

Grade DX51D / DX52D/ DX53D/ S250,280,320GD

Thickness 0.65~0.70mm

Place of Origin Shandong, China

Brand Name yk

Type Steel Coil

Technique Other, HOT DIP

Surface Treatment Galvanized

Application Flange Plate

Special Use Wear Resistant Steel

Width 1000mm

Specifications

the best cost
high in surface quality
convenient in deep-processing

The galvanized steel is to prevent the steel plate surface from corrosion and

prolong its service life, on the steel plate surface coated with a layer of metal zinc .

The galvanized steel has excellent plasticity, welding, impact resistance,

corrosion resistance and good coating.

goods	Hot dip galvanized steel coil and sheet
Technical Standard:	JIS 3302 / ASTM A653 / EN10143/EN10327
Grade	DX51D / DX52D/ DX53D/ S250,280,320GD
Width	500/650/726/820/914/1000/1200/1219/1220/1250mm
Thickness	0.17-1.6mm (0.25-0.45mm is the most advantage thickness)
Type of coating:	galvanized
Zinc coating	Z60-120g/m2
Surface treatment	chromed / skin pass/ oiled /un oiled /slightly oiled/ dry
Surface structure:	zero spangle / minimized spangle / regular spangle/ big spangle
ID coil	508mm or 610mm
Coil weight	2-8 MT per coil
Package:	Properly packed for ocean freight exportation in 20''containers
Price terms	FOB,CFR,CIF
Payment terms	30%TT in advance+70% TT or irrevocable 70%L/C at sight
delivery time	20 days after receipt of 30% TT

The industrial use

The application field	example illustration
The electrical appliance industry	Air conditioner,Computer chassis, Plate for refrigerator,Outer shell of washing machine,kitchen fittings, The freezing chamber device
The building industry	housetop,Lateral wall,doors and windows, gutter,Shutter doors and windows,Wall frame , Ceiling joist,ventiduct
The agricultural and pastoral	Granary,silo,animal house,trough,flume,Greenhouse trellis,Baking equipment;
The transport	railroad:The roof of the train,The internal frame of train,The road sign,The inner walls of the train; shipping:container,cold-formed-walled ; aviation:hangar,scutcheon; road:Highway guardrail,Soundproof wall
The equipment and structure	radiator,cold roll-formed ,Pedals and rack

The material and mechanical properties
