Phocos PWM-regulation Mini Solar Charge Controller

Name: Phocos PWM-regulation Mini Solar Charge Controller
Brand: Phocos
SKU: 110443445

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Phocos

Model Number:

CML

Qingdao Commercial Energy Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Phocos

Model Number CML

Application Charger Controller

Rated Voltage 12V

Specifications

PWM Mini Solar Charge Controller
1.Phocos brand
2.Battery charging with 3LEDS
3.12/24V auto detection
4.PWM-regulation

Phocos PWM-regulation Mini Solar Charge Controller

1. Battery State-of-Charge display with 3LEDS

2. Acoustic load disconnect pre-warning

3. PWM-regulation (series type)

4. Boost, Equalize and Float charging, also for VRLA

5. Automatic 12/24V detection

6. Integrated temperature compensation

7. Large terminals (up to 16 mm wire size)

8. SOC and voltage controlled LVD

9. Fully electronically protected

Technical data:

TYPE	CML 05		CML08	CML10	CML15		CML20
System voltage	12/24 V auto recognition
Max. charge/load current	5A	8A		10A	15A	20A
Float charge	13.7/27.4 V (25 °C)
Boost charge	14.4 /28.8V (25 °C), 2 Std. activation: battery voltage < 12.3/24.6 V
Equalization	14.8/29.6 V (25 °C), 2 Std. activation: battery voltage < 12.1/24.2 V
Deep discharge protection: State of charge dependent Voltage dependent Reconnect level	11.4-11.9 V/ 22.8- 23.8 V 11.0/22.0 V 12.8/25.6 V
Overvoltage protection	15.5/31.0 V
Undervoltage protection	10.5/21.0 V
Max. panel voltage (Overvoltage protection by varistor)	30 V in 12 V system 50 V in 24 V system
Temperature compensation (Charge voltage)	−25 mV/K at 12V −50 mV/K at 24V
Max. self consumption	< 4 mA
Grounding	positive grounding possible
Ambient temperature	−40 to +50 °C
Max. height	4,000 m above sea level
Battery type	lead acid (GEL, AGM, flooded)
Wire cross section	< 16 mm2
Weight	160 g
Dimensions (W x H x D)	80 x 100 x 32 mm
Type of protection	IP22
