WONTONNE hydraulic block clamps can efficiently & safely handle various types of solid, regular cubic goods under normal temperature.
WONTONNE Hydraulic Block Clamps
[Introduction]
WONTONNE hydraulic block clamps can efficiently and safely handle various types of solid, regular cubic goods under normal temperature. Hydraulic block clamps widely used in construction material, metallurgy industries for handling concrete blocks,cement bricks, carbon cubes, etc. The high structural strength and durability ensure the safe, productive application and long service life.
Features:
*Proven durable T-beam arm aluminum frame construction.
*Superior arm-side bearing for extended service life.
*Regenerative hydraulic valuing for optimal arm speed.
*Durable contact pads, reliable clamping.
*Excellent driver visibility.
Options:
*Custom opening ranges
*Custom pad sizes
*Load backrests
[Specification]
| Capacity/ Load Center (kg@mm) |
Type |
Mounting Class |
Opening Range (mm) |
Arm Height (mm) |
Arm Length (mm) |
Frame Width (mm) |
Overall Height (mm) |
Weight (kg) |
Effective Thickness (mm) |
Horizontal Center of Gravity (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| 2700/500 | CKS30D-001A | II | 290-1610 | 128 | 1100 | 1016 | 710 | 500 | 145 | 220 |
| 2700/500 | CKS30D-002A | II | 290-1610 | 242 | 1100 | 1016 | 710 | 550 | 145 | 220 |
| 2700/500 | CKS30D-003A | II | 290-1610 | 128 | 1000 | 1016 | 710 | 490 | 145 | 211 |
| 2700/500 | CKS30D-004A | III | 290-1610 | 128 | 1100 | 1016 | 710 | 500 | 152 | 220 |
| 2700/500 | CKS30D-005A | III | 290-1610 | 242 | 1100 | 1016 | 710 | 550 | 152 | 220 |
| 2700/500 | CKS30D-006A | III | 290-1610 | 128 | 1000 | 1016 | 710 | 490 | 152 | 220 |
| 2700/500 | CKS30D-007A | III | 290-1610 | 242 | 1400 | 1016 | 710 | 650 | 152 | 250 |
