XCMG Crawler Excavator XE150D

Name: XCMG Crawler Excavator XE150D
Brand: XCMG
SKU: 112296361

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

XCMG

Model Number:

XE150D

Shandong Zhongkai Machinery & Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name XCMG

Model Number XE150D

Condition New

Moving Type Crawler Excavator

Operating Weight 14,400kg

Bucket capacity 0.6

Maximum Digging Height 8,641mm

Maximum Digging Depth 5,538mm

Machine Weight 14000kg

Max Digging Radius 8,296mm

XCMG Crawler excavator XE150D

Features of XCMG Crawler excavator XE150D

1.Engine model-4BTAA3.9

2. Rated power:85.4kW/2200rpm
3. Invironment-friendly:certified to EPA and EC Tier2 standard

XCMG Crawler excavator XE150D Specifications

Model			XE150D
Bucket capacity		m3	0.6
Standard bucket width		mm	1,000
Operation weight		kg	14,400
Dimension (in transportation)	Overall length	mm	7,801
	Overall width	mm	2,590
	Overall height	mm	2,850
	Min. clearance	mm	478
Engine	Model		4BTAA3.9
	Total displacement	L	3.927
	Rated output power	KW/rpm	85.4/2200
Digging performance	Max. digging height	mm	8,641
	Max. dumping height	mm	6,181
	Max. digging depth	mm	5,538
	Max. vertical digging depth	mm	4,727
	Max. digging radius	mm	8,296
	Boom deflection angle	°
	Min. slew radius	mm	2,325
	Min. rear slew radius	mm	2,325
	Bucket digging force	kn	85
Track type			Steel
Track width		mm	600
Travel system	Track length	mm	3,660
	Wheel base	mm	2,910
	Track gauge	mm	1,990
	Travel speed (Gear I/II)	km/h	5.21/3.16
	Gradeability	%	70
Slew speed		rpm	12.3
Bulldozing plate	Bulldozing plate width	mm
	Bulldozing plate height	mm
	Lifting distance	mm
Hydraulic pump type			Variable pump×2 +gear pump×1
Slew motor type			Piston hydraulic motor
Travel motor type			Piston hydraulic motor
Fuel tank capacity		L	250
Hyraulic oil tank capacity		L	130
