XCMG Crawler Excavator XE215C

Name: XCMG Crawler Excavator XE215C
Brand: XCMG
SKU: 112296913

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

XCMG

Model Number:

XE215C

Shandong Zhongkai Machinery & Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name XCMG

Model Number XE215C

Condition New

Moving Type Crawler Excavator

Operating Weight 21500kg

Bucket capacity 0.91m3

Maximum Digging Height 6859mm

Maximum Digging Depth 6605mm

Machine Weight 13800kg

Max Digging Radius 9933mm

Specifications

XCMG Crawler Excavator XE215C
1. Operation Weight: 21.5 ton
2. Engine: ISUZU BB-6BG1TRP

XCMG Crawler Excavator XE215C

Parameter:

Model			XE215C
Bucket capacity		m³	0.91
Standard bucket width		mm
Operating weight		kg	21,500
Dimension (in transportation)	Overall length	mm	9,520
	Overall width	mm	2,990
	Overall height	mm	2,985
	Min. ground clearance	mm	485
Engine	Model		ISUZU BB-6BG1TRP
	Total displacement	L	6.494
	Rated output power	KW/rpm	106.5/1950
Digging performance	Max. digging height	mm	9,640
	Max. dumping height	mm	6,800
	Max. digging depth	mm	6,655
	Max. vertical digging depth	mm	5,695
	Max. digging radius	mm	9,925
	Boom deflection angle: left/right	°
	Min. slew radius	mm	3,530
	Min. rear slew radius	mm	2,750
	Bucket digging force	kn	138
Track type			Steel
Track width		mm	600
Travel system	Track overall length	mm	4,255
	Wheel base	mm	3,462
	Track gauge	mm	2,390
	Travel speed (Gear 1/2)	km/h	5.5/3.5
	Gradeability	%	70
Slew speed		rpm	13.3
Bulldozing plate	Bulldozing plate (width)	mm
	Bulldozing plate (height)	mm
	Lifting distance (GL up/down)	mm
Hydraulic pump type			Piston pump×2
Fuel tank capacity		L	360
Hydraulic oil tank capacity		L	220

Model			XE215C
Bucket capacity		m³	0.91
Standard bucket width		mm
Operating weight		kg	21,500
Dimension (in transportation)	Overall length	mm	9,520
	Overall width	mm	2,990
	Overall height	mm	2,985
	Min. ground clearance	mm	485
Engine	Model		ISUZU BB-6BG1TRP
	Total displacement	L	6.494
	Rated output power	KW/rpm	106.5/1950
Digging performance	Max. digging height	mm	9,640
	Max. dumping height	mm	6,800
	Max. digging depth	mm	6,655
	Max. vertical digging depth	mm	5,695
	Max. digging radius	mm	9,925
	Boom deflection angle: left/right	°
	Min. slew radius	mm	3,530
	Min. rear slew radius	mm	2,750
	Bucket digging force	kn	138
Track type			Steel
Track width		mm	600
Travel system	Track overall length	mm	4,255
	Wheel base	mm	3,462
	Track gauge	mm	2,390
	Travel speed (Gear 1/2)	km/h	5.5/3.5
	Gradeability	%	70
Slew speed		rpm	13.3
Bulldozing plate	Bulldozing plate (width)	mm
	Bulldozing plate (height)	mm
	Lifting distance (GL up/down)	mm
Hydraulic pump type			Piston pump×2
Fuel tank capacity		L	360
Hydraulic oil tank capacity		L	220
