National Initiative
CNC DUAL FAST WIRE CONTOUR FOAM CUTTER
Profiles a wide variety of foam
With an abrasive cutting wire running in excess of 88m/sec, the Haien Fastwire machine can profile a wide range of rigid and flexible foams, including:
1. Flexible and rigid polyurethane (PU) foams
2. EVA foam
3. Expanded Polystyrene (EPS) foam
4. Rockwool
5. Poly-ethylene (PE) foam
6. Rebond or chip foam
7. Phenolic foams (conditions apply)
8. PVC foam
Summary
Haien’s range of computer controlled Contour Machine Cutters are designed to help foam converters improve their productivity, efficiency and quality.
The benefits of using a Haien Contour Cutter are summarized below:
Compared to hand controlled contour cutting systems
1. Accuracy and repeatability with less reliance on operator skill.
2. No rejects due to operator fatigue or error.
3. Improved safety with remote operation.
4. Much higher production output.
5. Big Cost savings by eliminating the need to make, repair and store templates.
6. Higher material utilization resulting from computer aided nesting of shapes.
7. The capacity to change designs and prepare prototypes in minutes.
TYPE: |
HW-FM20HL |
HW-FM12HL |
Max Cutting Size |
L3000mm W2200mm H1150mm |
L3000mm W1200mm H1150mm |
Cutting material density |
10~350kg/m3 |
10~350kg/m3 |
Working voltage of controller |
5V /24V /36V |
5V / 24V/36V |
Control precision(mm) |
0.01mm |
0.01mm |
General Power |
13KW |
11kw |
380V ,50HZ |
380V ,50HZ |
|
Wire Size(mm) |
φ1.3~ φ2.0*10930&10350 |
φ1.3~ φ2.0*9130&9765 |
Cutting wheel(mm) |
φ300 mm |
φ300 mm |
Max. cutting speed (m/min) |
0~10m/min |
0~10m/min |
Processing precision (mm) |
±0.5mm |
±0.5mm |
Min. Arc Size of work pieces(mm) |
R5 |
R5 |
G.W. |
4800kg |
3800kg |
CNC System |
Standard |
Standard |
Control axis |
X /Y1/Y2 |
X/Y1/Y2 |
Wire break protect |
Set |
Set |
Remote control |
Manual/semi-auto |
Manual/semi-auto |
G code/dxf |
Standard |
Standard |
Air pressure |
0~6Mpa |
0~6Mpa |
Dust collecter |
3~ /3KW/380V/50HZ |
3~/3KW/380V/50HZ |
Wire Position detection |
Photoelectric |
Photoelectric |
Wire tension |
Auto |
Auto |
Wire running speed adjust |
Frequency changer |
Frequency changer |
Wire max running speed |
3000r/min |
3000r/min |
Floor Space (m) |
6.2*4.5*2.72 |
6.2*3.5*2.68 |
