Help CenterDZ601-24 Single Phase Meter Test Equipment
Related Products
-
DZ601-48 Digital Smart Kwh Meter Test Equipment for Single PhaseUS$ 18,000 - 25,000MOQ: 1 Set -
DZ601-48 Single Phase Energy Meter Testing Bench(SMS)US$ 20,000 - 25,000MOQ: 1 Set
-
DZ601-48 Single Phase Intelligent Energy Meter Testing Equipment With High AccuracyUS$ 20,000 - 25,000MOQ: 1 Set
-
DZ603-24 Three Phase KWH Meter Test InstrumentUS$ 2,000 - 31,000MOQ: 1 Set
-
Single Phase Energy Meter Test Equipment With 60 Meter PositionsUS$ 20,000 - 25,000MOQ: 1 Set
Specifications
1. Test all items as per IEC and ANSI2. Certificate: ISO 9001
3. Accuracy class: 0.05
4.18 years professional experience
18 years professional experience
produce as your personal requirement
low price and excellent quality
excellent after-sales service
Specifications
1. Automated meter test equipment
2.Certificate: ISO 9001;
3.Accuracy class: 0.05, 0.1;
4.Excellent aftersale service
DZ601-24 Single Phase Energy Meter test equipment
Main functions and features:
1- apply to test all kinds of single-phase energy meter
2- simultaneous measurements for energy meters with the same spec but different meter constant or different accuracy class.
3- operation mode:SMS special keyboard and SMS PC software control
4- display mode: error indicator on each meter position / PC monitor
5- support below test items, include:
no-load test
start test
basis errors test
meter constant test
voltage influence test
meter reverse turn test
energy counting test
6- Auto-turnning up of photoelectrical scanning head
7- full-automatic current/voltage measuring range switching
8- auto-alarming protection against output voltage short circuit and current open circuit
9- auto capturing the black dot on the rotor before starting test and no-load test
10- Harmonic setting
11- Waveform display
12- keyboard current load testing point setting in common use: Imax4Ib2Ib1.5Ib1.0Ib0.5Ib0.2Ib0.1Ib, 0.05Ib
13- keyboard voltage load testing point setting in common use: 1.2(1.15)Un1.1Un1.0Un0.8Un
14- keyboard phasor testing point setting in common use:0.5C,0.5L, 1, 0.8C,0.8L
15- programmable Voltage/ current/ frequency and phase angle
16- support bar code input, error curve, error limit setting , multi-mode calibration plans setting and equipment authoriy by PC software
17- support data processing and verification certificate printting with customized table format
18- communication test. Specially equiped with RS485 communicaiton box for the impulse receiving and switching in order to test electronic multi-function meter (optional function)
19- able to measure and save the circumstance temperature and relative humidity (optional function)
20- forced device warmingup function can gurantee the accuracy and normal running.(optional)
Index:
1)Accuracy classes: 0.05,0.1,0.2.
2)Model: DZ601-24( meter position can be customized)
3)Equipped with 0.05 class three phase reference standard meter
4)The maximum output current: 120A; Ranges: 0.1A, 0.5A, 1.0A, 2.5A, 5A, 10A, 20A,
50A, 100A
5)Voltage is divided into four ranges: 57.7V, 100V, 220V, 380V
6)Voltage output power: 280VA per phase, current power: 450VA per phase
7)For each range of current and voltage, 0~120% of the range value can be
continually adjusted, the resolution is better than 0.01% of range value
8)Accuracy of Indication Meter:
Voltage meter: class 0.5, Current meter: class 0.5,
Frequency meter: class0.3 phase meter: class 0.3
9)Phase scope 0~359.9 degrees, adjusted resolution is 0.1 degree
10)Testing points of power factor: 0.5C, 0.8C, 1.0, 0.8L, 0.5L
11)Range of frequency is from 45.00 to 65.00Hz, adjusted resolution is 0.01Hz
12)Shall set and measure 2-21 times harmonic and measure the distortion
13)Output power stability: 0.05%(PF=1.100Sec)
14)Wave distortion of outputting: < 1%
15)Voltage supply: AC220V+/-10% 50Hz
Annotation:we can produce three or single phase energy meter test bench with 3-60 meter positions according to your requirements.
1. Packing & Shipping
Packed in Plywood case
Deliver the goods within one month after receiving the prepayment
1. We can produce the single phase meter test bench/single phase energy meter instrument/single phase electricity meter test equipment according to client's requirement.
2. Good after-sale service, and good quality.
3. All our products can test all items such as Per IEC and ANSI
1. What is the advantages of your products?
Thanks for your inquiry. Our products' advantages is that all products achieve the standard of IEC and ANSI.
And our goods have been exported to many countries in the world, such as Korea, India, Russion, Pakistan, Vietnam ans so on. The quality is excellent that it wins lot reputation for us.
2. What is the shelf life for your products?
Thanks for your consideration. The shelf life of our products is 3 years. (Our company is responsible for the repairing and maintaining free of charge)
3. What terms of trade your company accept?
Thanks for your consideration. Our company accepts T/T, L/C, Western Union. Thanks for your understanding.
